EATON - MOELLER 46KV 6A LK 46KV 6A LK 46TB6 EATON ELECTRIC Cartridge fuse, expulsion, MT, 6 A, AC 46 kV, 787 mm, ANSI a, T slow View larger
Images are for illustrative purposes only. Please refer to data sheet for details

46KV 6A LK 46TB6 EATON ELECTRIC Cartridge fuse, expulsion, MT, 6 A, AC 46 kV, 787 mm, ANSI a, T slow

46KV 6A LK

46TB6

46TB6

EATON - MOELLER

25 Pcs.

Cartridge fuse, expulsion, MT, 6 A, AC 46 kV, 787 mm, ANSI a, T slow 46KV 6A LK Expulsion fuse-link, medium voltage, 6 A, AC 46 kV, 787 mm, ANSI, T slow, style B termination Fuse, Expulsion fuse-link, medium voltage, 6 A, AC 46 kV, 787 mm, ANSI, T slow, fixed NEMA button head link, protection of transformer primary side, feeder, capacitor bank, ANSI C37-42, Breaking Capacity 8 kA

Automation > Expulsion fuse-link, medium voltage
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Utilities rely on components such as the Eaton Moeller 46KV 6A LK cartridge fuse to interrupt abnormal fault currents on overhead power lines. These protective elements ensure that localized faults do not cascade into broader electrical failures across the network. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated current (EF000227): 6 A
  • Rated voltage (EF000228): 46 kV
  • Voltage type (EF000187): AC
  • Rated frequency (EF001663): 50 Hz
  • Release characteristic (EF000889): T
  • Type of termination (EF012540): Fixed buttonhead
  • Standard (EF009322): ANSI

More info

▲

General specifications

Product Name
Eaton Bussmann series medium voltage expulsion fuse
Catalog Number
46TB6
EAN
5027590481649
Product Length/Depth
225 mm
Product Height
76 mm
Product Width
106 mm
Product Weight
20.04 g
Certifications
ANSI/IEEE Std C37.42

Electrical data

Amperage Rating
6 A
Voltage rating
46 kV
Voltage type
AC
Current characteristic type
Type T - Complies with ANSI C 37-42 requirements for slow acting T characteristics
Rated frequency - min
50 Hz

Product specification

Construction size
787 mm
Standard
ANSI
Type of termination
Fixed buttonhead
Color
Green
