EATON - MOELLER 46KV 100A LK 46KV 100A LK 46TU100 EATON ELECTRIC Cartridge fuse, expulsion, MT, 100 A, AC 46 kV, 787 mm, ANSI a, T slow View larger
Images are for illustrative purposes only. Please refer to data sheet for details

46KV 100A LK 46TU100 EATON ELECTRIC Cartridge fuse, expulsion, MT, 100 A, AC 46 kV, 787 mm, ANSI a, T slow

46KV 100A LK

46TU100

46TU100

EATON - MOELLER

10 Pcs.

Cartridge fuse, expulsion, MT, 100 A, AC 46 kV, 787 mm, ANSI a, T slow 46KV 100A LK Expulsion fuse-link, medium voltage, 100 A, AC 46 kV, 787 mm, ANSI, T slow, style U termination Fuse, Expulsion fuse-link, medium voltage, 100 A, AC 46 kV, 787 mm, ANSI, T slow, universal with slip off NEMA button head, protection of transformer primary side, feeder, capacitor bank, ANSI C37-42, Breaking Capacity 8 kA

Automation > Expulsion fuse-link, medium voltage
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Engineered for heavy-duty circuit protection, the Eaton Moeller 46KV 100A LK functions as an expulsion cartridge fuse within demanding medium voltage electrical installations. Utilities install these specialized links to protect critical distribution transformers and feeder lines against high-level short circuits and overloads.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated current (EF000227): 100 A
  • Rated voltage (EF000228): 46 kV
  • Voltage type (EF000187): AC
  • Rated frequency (EF001663): 50 Hz
  • Release characteristic (EF000889): T
  • Type of termination (EF012540): Universal
  • Standard (EF009322): ANSI

More info

▲

General specifications

Product Name
Eaton Bussmann series medium voltage expulsion fuse
Catalog Number
46TU100
EAN
5027590481908
Product Length/Depth
225 mm
Product Height
76 mm
Product Width
106 mm
Product Weight
0.162 g
Certifications
ANSI/IEEE Std C37.42

Electrical data

Amperage Rating
100 A
Voltage rating
46 kV
Voltage type
AC
Current characteristic type
Type T - Complies with ANSI C 37-42 requirements for slow acting T characteristics
Rated frequency - min
50 Hz

Product specification

Construction size
787 mm
Standard
ANSI
Type of termination
Universal
Color
Green

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
