EATON - MOELLER 3.6KV 6.3Amp 2" 'A' Air Fuse ADG 3.6KV 6.3Amp 2" 'A' Air Fuse ADG 3.6ADGHA6.3 3-6ADGHA6-3 EATON ELECTRIC Air fuse-link, medium voltage, 6.3 A.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

3.6KV 6.3Amp 2" 'A' Air Fuse ADG 3.6ADGHA6.3 3-6ADGHA6-3 EATON ELECTRIC Air fuse-link, medium voltage, 6.3 A..

3.6KV 6.3Amp 2" 'A' Air Fuse ADG

36ADGHA63

3-6ADGHA6-3

EATON - MOELLER

3 Pcs.

3.6KV 6.3Amp 2" 'A' Air Fuse ADG 3.6KV 6.3Amp 2" 'A' Air Fuse ADG - Air fuse-link, medium voltage, 6.3 A, AC 3.6 kV, 51 x 359 mm, back-up, BS, with striker Fuse, Air fuse-link, medium voltage, 6.3 A, AC 3.6 kV, 51 x 359 mm, back-up, BS, with striker, cylindrical, protection of primary side transformers, BS2692-1

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Eaton Moeller 3.6KV 6.3Amp 2" 'A' Air Fuse ADG provides dependable medium voltage circuit protection for primary transformer installations. Protection devices of this caliber disconnect electrical faults cleanly, minimizing downtime and mitigating risk in industrial electrical systems.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated current (EF000227): 6.3 A
  • Rated voltage (EF000228): 3.6 kV
  • Voltage type (EF000187): AC
  • Rated frequency (EF001663): 50 Hz
  • Breaking capacity (EF005617): 40 kA
  • Application (EF000041): Primary side transformer protection
  • Length (EF001438): 359 mm
  • Diameter (EF000551): 51 mm
  • Performance category according to IEC 60282-1 (EF012539): Back-up
  • With striker (EF008175): Yes
  • Standard (EF009322): British Standard
  • Installation technique (EF001474): Air

More info

▲
Air fuse-link, medium voltage, 6.3 A, AC 3.6 kV, 51 x 359 mm, back-up, BS, with striker
Fuse, Air fuse-link, medium voltage, 6.3 A, AC 3.6 kV, 51 x 359 mm, back-up, BS, with striker, cylindrical, protection of primary side transformers, BS2692-1

Delivery program

Product range
Fuse
Basic function
Air fuse-link
Field of application
medium voltage
Rated current [I]
6.3 A
Rated voltage
AC 3.6 kV
Size
51 x 359 mm
Utilization category
back-up
Status indicator
with striker
usable for size/applications
protection of primary side transformers
Standard/Approval
BS
Shape
cylindrical
Standards/Regulations
BS2692-1

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
6.3 A
Rated voltage
3.6 kV
Voltage type
AC
Rated frequency
50 - 50 Hz
Breaking capacity
25 kA
Utilization category
Other
Application
Primary side transformer protection
Length
359 mm
Diameter
51 mm
Performance category according to IEC 60282-1
Back-up
With striker
Yes
Standard
British Standard
Release characteristic
Other
Installation technique
Air
