36KV 40AMP FUSE 36AFING40 EATON ELECTRIC Fuse, Air fuse-link, medium voltage, 10 A, AC 12 kV, 51 x 359 mm, b..
36KV 40AMP FUSE
36AFING40
EATON - MOELLER
1 Pcs.
Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Eaton Moeller 36KV 40AMP FUSE functions as a specialized medium voltage air fuse-link integrated into electrical networks for primary side transformer protection. It provides essential current-limiting performance to isolate faults before they can propagate through the power network.
Pricing, availability, and lead time are confirmed per enquiry through an RFQ.
- Rated current (EF000227): 40 A
- Rated voltage (EF000228): 36 kV
- Voltage type (EF000187): AC
- Rated frequency (EF001663): 50 Hz
- Breaking capacity (EF005617): 25 kA
- Application (EF000041): Primary side transformer protection
- Length (EF001438): 565 mm
- Diameter (EF000551): 76 mm
- Performance category according to IEC 60282-1 (EF012539): Back-up
- With striker (EF008175): No
- Standard (EF009322): British Standard
- Installation technique (EF001474): Air
More info
▲Delivery program
used in fuse switch combination units, fuse bases and fuse switches
