36KV 3.15AMP 2" OIL FUSE 36ODGN293.15 36ODGN293-15 EATON ELECTRIC Fuse, Air fuse-link, medium voltage, 25 A,..
36KV 3.15AMP 2" OIL FUSE
36ODGN29315
36ODGN293-15
EATON - MOELLER
3 Pcs.
Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Eaton Moeller 36KV 3.15AMP 2" OIL FUSE is built for high-voltage electrical environments, providing dependable circuit isolation and asset protection. Fuses of this classification are typically deployed in specialized distribution infrastructure to manage high-voltage fault currents safely. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Rated current (EF000227): 3.15 A
- Rated voltage (EF000228): 36 kV
- Voltage type (EF000187): AC
- Rated frequency (EF001663): 50 Hz
- Breaking capacity (EF005617): 31.5 kA
- Application (EF000041): Primary side transformer protection
- Length (EF001438): 361.64 mm
- Diameter (EF000551): 51 mm
- Performance category according to IEC 60282-1 (EF012539): Back-up
- With striker (EF008175): Yes
- Standard (EF009322): British Standard
- Installation technique (EF001474): Oil
More info
▲Delivery program
IEC 60282-1
