EATON - MOELLER 36KV 31.5AMP 3" AIR FUSE 36KV 31.5AMP 3" AIR FUSE 36AFIH3631.5 36AFIH3631-5 EATON ELECTRIC Air fuse-link, medium voltage, 31.5 A, AC .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

36KV 31.5AMP 3" AIR FUSE 36AFIH3631.5 36AFIH3631-5 EATON ELECTRIC Air fuse-link, medium voltage, 31.5 A, AC ..

36KV 31.5AMP 3" AIR FUSE

36AFIH36315

36AFIH3631-5

EATON - MOELLER

1 Pcs.

Air fuse-link, medium voltage, 31.5 A, AC 36 kV, 76.2 X 565mm, back-up, BS, with striker, style 36 tags 36KV 31.5AMP 3" AIR FUSE 36KV 31.5AMP 3" AIR FUSE - Air fuse-link, medium voltage, 31.5 A, AC 36 kV, 25 kA, 76.2 X 565mm, back-up, BS, with striker Fuse, Air fuse-link, medium voltage, 31.5 A, AC 36 kV, 76.2 X 565mm, back-up, BS, with striker, cylindrical, protection of primary side transformers, used in fuse switch combination units, fuse bases and fuse switches, BS 2692-1, Breaking Capacity 25 kA, Optional accessories, Supplied with

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Utilized in air-insulated electrical switchgear, the Eaton Moeller 36KV 31.5AMP 3" AIR FUSE functions as a medium voltage air fuse-link dedicated to primary side transformer protection. It provides rapid fault isolation to maintain overall grid reliability.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Rated current (EF000227): 31.5 A
  • Rated voltage (EF000228): 36 kV
  • Voltage type (EF000187): AC
  • Rated frequency (EF001663): 50 Hz
  • Breaking capacity (EF005617): 25 kA
  • Application (EF000041): Primary side transformer protection
  • Length (EF001438): 565 mm
  • Diameter (EF000551): 76 mm
  • Performance category according to IEC 60282-1 (EF012539): Back-up
  • With striker (EF008175): Yes
  • Standard (EF009322): British Standard
  • Installation technique (EF001474): Air

More info

▲
Air fuse-link, medium voltage, 31.5 A, AC 36 kV, 25 kA, 76.2 X 565mm, back-up, BS, with striker
Fuse, Air fuse-link, medium voltage, 31.5 A, AC 36 kV, 76.2 X 565mm, back-up, BS, with striker, cylindrical, protection of primary side transformers, used in fuse switch combination units, fuse bases and fuse switches, BS 2692-1, Breaking Capacity 25 kA

Delivery program

Product range
Fuse
Basic function
Air fuse-link
Field of application
medium voltage
Rated current [I]
31.5 A
Rated voltage
AC 36 kV
Size
76.2 X 565mm
Utilization category
back-up
Status indicator
with striker
Breaking Capacity
25 kA
usable for size/applications
protection of primary side transformers
used in fuse switch combination units, fuse bases and fuse switches
Standard/Approval
BS
Shape
cylindrical
Standards/Regulations
BS 2692-1

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
31.5 A
Rated voltage
36 kV
Voltage type
AC
Rated frequency
50 - 50 Hz
Breaking capacity
25 kA
Utilization category
Other
Application
Primary side transformer protection
Length
565 mm
Diameter
76 mm
Performance category according to IEC 60282-1
Back-up
With striker
Yes
Standard
British Standard
Release characteristic
Other
Installation technique
Air
