EATON - MOELLER 3.6KV 10AMP FUSE 10 3.6 3.6KV 10AMP FUSE 10 3.6 3.6ABCNA10 3-6ABCNA10 EATON ELECTRIC VT fuse-link, medium voltage, 10 A, AC 3.6 kV, .. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

3.6KV 10AMP FUSE 10 3.6 3.6ABCNA10 3-6ABCNA10 EATON ELECTRIC VT fuse-link, medium voltage, 10 A, AC 3.6 kV, ..

3.6KV 10AMP FUSE 10 3.6

36ABCNA10

3-6ABCNA10

EATON - MOELLER

1 Pcs.

VT fuse-link, medium voltage, 10 A, AC 3.6 kV, 25.4 x 195 mm, back-up, BS, IEC 3.6KV 10AMP FUSE 10 3.6 Fuse, VT fuse-link, medium voltage, 10 A, AC 3.6 kV, 25.4 x 195 mm, back-up, BS, IEC, cylindrical, voltage and auxiliary transformers, BS2692-1, IEC 60282-1, Breaking Capacity 50 kA

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Eaton Moeller 3.6KV 10AMP FUSE 10 3.6 functions as an auxiliary voltage transformer fuse designed to protect measurement and control hardware in switchgear assemblies. This IEC-compliant link isolates potential transformers during internal electrical faults. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated current (EF000227): 10 A
  • Rated voltage (EF000228): 3.6 kV
  • Voltage type (EF000187): AC
  • Breaking capacity (EF005617): 50 kA
  • Application (EF000041): Auxiliary transformer protection
  • Length (EF001438): 195 mm
  • Performance category according to IEC 60282-1 (EF012539): Back-up
  • With striker (EF008175): No
  • Standard (EF009322): IEC
  • Installation technique (EF001474): Air

More info

▲
VT fuse-link, medium voltage, 10 A, AC 3.6 kV, 50 kA, 25.4 x 195 mm, back-up, BS, IEC
Fuse, VT fuse-link, medium voltage, 10 A, AC 3.6 kV, 25.4 x 195 mm, back-up, BS, IEC, cylindrical, voltage and auxiliary transformers, BS2692-1, IEC 60282-1, Breaking Capacity 50 kA

Delivery program

Product range
Fuse
Basic function
VT fuse-link
Field of application
medium voltage
Rated current [I]
10 A
Rated voltage
AC 3.6 kV
Size
25.4 x 195 mm
Utilization category
back-up
Breaking Capacity
50 kA
usable for size/applications
voltage and auxiliary transformers
Standard/Approval
BS
IEC
Shape
cylindrical
Standards/Regulations
BS2692-1
IEC 60282-1

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
10 A
Rated voltage
3.6 kV
Voltage type
AC
Rated frequency
50 - 50 Hz
Breaking capacity
50 kA
Utilization category
Other
Application
Auxiliary transformer protection
Length
254 mm
Diameter
25.4 mm
Performance category according to IEC 60282-1
Back-up
With striker
No
Standard
IEC
Release characteristic
Other
Installation technique
Air
