EATON - MOELLER 36KV 10AMP 2" OIL FUSE 36KV 10AMP 2" OIL FUSE 36ODGNA10 EATON ELECTRIC Oil fuse-link, medium voltage, 10 A, AC 12 kV, 50.8 x 203 mm.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

36KV 10AMP 2" OIL FUSE 36ODGNA10 EATON ELECTRIC Oil fuse-link, medium voltage, 10 A, AC 12 kV, 50.8 x 203 mm..

36KV 10AMP 2" OIL FUSE

36ODGNA10

EATON - MOELLER

3 Pcs.

Oil fuse-link, medium voltage, 10 A, AC 12 kV, 50.8 x 203 mm, back-up, BS 36KV 10AMP 2" OIL FUSE 36KV 10AMP 2" OIL FUSE - Oil fuse-link, medium voltage, 10 A, AC 36 kV, 31.5 kA, 2", 50.8 x 359 mm, back-up, BS, no striker, oil-tight Fuse, Oil fuse-link, medium voltage, 10 A, AC 36 kV, 50.8 x 359 mm, back-up, BS, cylindrical, voltage and auxiliary transformers, BS 2692-1, IEC 60282-1, Breaking Capacity, Optional accessories, Supplied with

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Oil fuse-link, medium voltage, 10 A, AC 36 kV, 31.5 kA, 2", 50.8 x 359 mm, back-up, BS, no striker, oil-tight
Fuse, Oil fuse-link, medium voltage, 10 A, AC 36 kV, 50.8 x 359 mm, back-up, BS, cylindrical, voltage and auxiliary transformers, BS 2692-1, IEC 60282-1

Delivery program

Product range
Fuse
Basic function
Oil fuse-link
Field of application
medium voltage
Rated current [I]
10 A
Rated voltage
AC 36 kV
Construction size
2"
Size
50.8 x 359 mm
Utilization category
back-up
Status indicator
no striker
Description
oil-tight
Breaking Capacity
31.5 kA
usable for size/applications
voltage and auxiliary transformers
Standard/Approval
BS
Shape
cylindrical
Standards/Regulations
BS 2692-1
IEC 60282-1

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
10 A
Rated voltage
36 kV
Voltage type
AC
Rated frequency
50 - 50 Hz
Breaking capacity
kA
Utilization category
Other
Application
Auxiliary transformer protection
Length
359 mm
Diameter
51 mm
Performance category according to IEC 60282-1
Back-up
With striker
No
Standard
British Standard
Release characteristic
Other
Installation technique
Oil

ETIM for 36ODGNA10 Circuit breakers and fuses (EC003507)
Feature Name Feature Value
Rated current (EF000227) 10 A
Rated voltage (EF000228) 36 kV
Voltage type (EF000187) AC
Rated frequency (EF001663) 50 Hz
Breaking capacity (EF005617) 50 kA
Utilization category according to IEC 60269 (EF002572) Other
Application (EF000041) Primary side transformer protection
Length (EF001438) 359 mm
Diameter (EF000551) 51 mm
Performance category according to IEC 60282-1 (EF012539) Back-up
With striker (EF008175) Yes
Standard (EF009322) British Standard
Release characteristic (EF000889) Other
Installation technique (EF001474) Oil

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
