EATON - MOELLER 3.6KV 40Amp 2" 'O' Air Fuse ADF 3.6KV 40Amp 2" 'O' Air Fuse ADF 3.6ADFHO40 3-6ADFHO40 EATON ELECTRIC Air fuse-link, medium voltage, 40 A, AC.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

3.6KV 40Amp 2" 'O' Air Fuse ADF 3.6ADFHO40 3-6ADFHO40 EATON ELECTRIC Air fuse-link, medium voltage, 40 A, AC..

3.6KV 40Amp 2" 'O' Air Fuse ADF

36ADFHO40

3-6ADFHO40

EATON - MOELLER

3 Pcs.

Air fuse-link, medium voltage, 40 A, AC 3.6 kV, 51 x 254 mm, back-up, BS, with striker 3.6KV 40Amp 2" 'O' Air Fuse ADF 3.6KV 40Amp 2" 'O' Air Fuse ADF - Air fuse-link, medium voltage, 40 A, AC 3.6 kV, 40 kA, 51 x 254 mm, back-up, BS, with striker Fuse, Air fuse-link, medium voltage, 40 A, AC 3.6 kV, 51 x 254 mm, back-up, BS, with striker, cylindrical with offset bolted tags, protection of primary side transformers, used in fuse switch combination units, fuse bases and fuse switches, BS2692-1, Breaking Capacity 40 kA

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Air fuse-link, medium voltage components like the Eaton Moeller 3.6KV 40Amp 2" 'O' Air Fuse ADF offer reliable overload protection for utility and industrial transformers. Medium-voltage fuses quickly isolate system faults to protect expensive electrical networks. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated current (EF000227): 40 A
  • Rated voltage (EF000228): 3.6 kV
  • Voltage type (EF000187): AC
  • Rated frequency (EF001663): 50 Hz
  • Breaking capacity (EF005617): 40 kA
  • Application (EF000041): Primary side transformer protection
  • Length (EF001438): 254 mm
  • Diameter (EF000551): 51 mm
  • Performance category according to IEC 60282-1 (EF012539): Back-up
  • With striker (EF008175): Yes
  • Standard (EF009322): British Standard
  • Installation technique (EF001474): Air

More info

▲
Air fuse-link, medium voltage, 40 A, AC 3.6 kV, 40 kA, 51 x 254 mm, back-up, BS, with striker
Fuse, Air fuse-link, medium voltage, 40 A, AC 3.6 kV, 51 x 254 mm, back-up, BS, with striker, cylindrical with offset bolted tags, protection of primary side transformers, used in fuse switch combination units, fuse bases and fuse switches, BS2692-1, Breaking Capacity 40 kA

Delivery program

Product range
Fuse
Basic function
Air fuse-link
Field of application
medium voltage
Rated current [I]
40 A
Rated voltage
AC 3.6 kV
Size
51 x 254 mm
Utilization category
back-up
Status indicator
with striker
Breaking Capacity
40 kA
usable for size/applications
protection of primary side transformers
used in fuse switch combination units, fuse bases and fuse switches
Standard/Approval
BS
Shape
cylindrical with offset bolted tags
Standards/Regulations
BS2692-1

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
40 A
Rated voltage
3.6 kV
Voltage type
AC
Rated frequency
50 - 50 Hz
Breaking capacity
40 kA
Utilization category
Other
Application
Primary side transformer protection
Length
254 mm
Diameter
51 mm
Performance category according to IEC 60282-1
Back-up
With striker
Yes
Standard
British Standard
Release characteristic
Other
Installation technique
Air

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
