17.5KV 40AMP 2" DIN FUSE 17.5TDLSJ40 17-5TDLSJ40 EATON ELECTRIC Fuse-link, medium voltage, 40 A, AC 17.5 kV,..
17.5KV 40AMP 2" DIN FUSE
175TDLSJ40
17-5TDLSJ40
EATON - MOELLER
3 Pcs.
Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Eaton Moeller 17.5KV 40AMP 2" DIN FUSE serves as a medium voltage fuse-link for safeguarding primary transformer circuits in electrical distribution networks. These parts are installed within standard switchgear enclosures to maintain network stability. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Rated current (EF000227): 40 A
- Rated voltage (EF000228): 17.5 kV
- Voltage type (EF000187): AC
- Rated frequency (EF001663): 50 Hz
- Breaking capacity (EF005617): 35.5 kA
- Application (EF000041): Primary side transformer protection
- Length (EF001438): 292 mm
- Diameter (EF000551): 51 mm
- Performance category according to IEC 60282-1 (EF012539): Back-up
- With striker (EF008175): Yes
- Standard (EF009322): DIN
- Installation technique (EF001474): Air
More info
▲Delivery program
indoor use
VDE 0670-4
VDE 0670-402
IEC 60282-1
