EATON - MOELLER 160NHM2B-690 160NHM2B-690 EATON ELECTRIC Fuse-link, low voltage, 100 A, AC 690 V, NH00, aM, IEC, dual indicator View larger
Images are for illustrative purposes only. Please refer to data sheet for details

160NHM2B-690 EATON ELECTRIC Fuse-link, low voltage, 100 A, AC 690 V, NH00, aM, IEC, dual indicator

160NHM2B-690

160NHM2B690

EATON - MOELLER

3 Pcs.

NH FUSE 160AMP 690V AM SIZE 2 DUAL IND 160NHM2B-690 - Fuse-link, LV, 160 A, AC 690 V, NH2, aM, IEC, dual indicator, live gripping lugs Fuse, fuse-link, low voltage, 160 A, AC 690 V, NH2, aM, IEC, dual (combination) indicator system, square-body with knife blade contacts, live gripping lugs, IEC 60269-2 fuse system A, DIN 43620, VDE 0636-2. Breaking capacity 120 kA

Automation > Low Voltage HRC fuse
Bussmann Series Low Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Fuse-link, LV, 160 A, AC 690 V, NH2, aM, IEC, dual indicator, live gripping lugs
Fuse, fuse-link, low voltage, 160 A, AC 690 V, NH2, aM, IEC, dual (combination) indicator system, square-body with knife blade contacts, live gripping lugs, IEC 60269-2 fuse system A, DIN 43620, VDE 0636-2. Breaking capacity 120 kA

General specifications
Product name
Eaton Bussmann series low voltage NH Fuse
Part no.
160NHM2B-690
EAN
5027590437448
Product Length/Depth
150 millimetre
Product height
71 millimetre
Product width
54 millimetre
Product weight
652 gram
Compliances
CE Marked
RoHS Compliant
Certifications
DIN 43620
IEC 60269-2
IEC 60269-1
Product Tradename
None
Product Type
Low voltage NH fuse
Product Sub Type
None
Electrical data
Amperage Rating
160 A
Voltage rating
690 V
Voltage type
AC
Breaking capacity
120 kA
Class
Class aM
Frequency rating - min
45 Hz
Frequency rating - max
62 Hz
Product specifications
Fuse size
NH2
Insulated metal gripping lugs (IMGL)
No
Accessories
Suitable for
SD2-D Single pole NH Fuse base
TD2-D Tripe pole NH Fuse base
Microswitch 170H0235
Microswitch 170H0236
EBH Size 00 to 4 Horizontal fuse switch-disconnectors

Technical data ETIM 8.0

Circuit breakers and fuses (EG000020) / Knife blade fuse (EC000055)
Electric engineering, automation, process control engineering / Electrical installation, device / Safety fuse inserts / Low-Voltage HRC fuse ([email protected] [AFZ800015])
Fuse construction type according to IEC 60269
NH2
Voltage type
AC
Rated current
160 A
Rated voltage AC
690 V
Rated voltage DC
V
Rated switching capacity
120 kA
Utilization category
aM (switchgear protection)
Type of fuse status indicator
Combination fuse status indicator
Insulated metal gripping lugs (IMGL)
No
Power loss at rated current
11 W

ETIM for 160NHM2B-690 Circuit breakers and fuses (EC000055)
Feature Name Feature Value
Fuse construction type according to IEC 60269 (EF015865) NH2
Voltage type (EF000187) AC
Rated current (EF000227) 160 A
Rated voltage AC (EF007682) 690 V
Rated switching capacity AC (EF017698) 120 kA
Utilization category according to IEC 60269 (EF002572) aM (switchgear protection)
Type of fuse status indicator (EF004473) Combination fuse status indicator
Insulated metal gripping lugs (IMGL) (EF012538) No
Power loss at rated current (EF012389) 11 W
