View larger
Images are for illustrative purposes only. Please refer to data sheet for details
15KV 8AMP EXPULSION LINK 15KD8 EATON ELECTRIC Expulsion fuse-link, medium voltage, 8 A, AC 15 kV, 533 mm, AN..
15KV 8AMP EXPULSION LINK
15KD8
EATON - MOELLER
25 Pcs.
Expulsion fuse-link, medium voltage, 8 A, AC 15 kV, 533 mm, ANSI, K fast, style D termination
15KV 8AMP EXPULSION LINK
Automation > Expulsion fuse-link, medium voltage
Bussmann Series Medium Voltage fuses and accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Expulsion fuse-link, medium voltage, 8 A, AC 15 kV, 533 mm, ANSI, K fast, style D termination
Fuse, Expulsion fuse-link, medium voltage, 8 A, AC 15 kV, 533 mm, ANSI, K fast, Double tailed link without NEMA button head, protection of transformer primary side, feeder, capacitor bank, ANSI C37-42, Breaking Capacity 8 kA
Technical data ETIM 7.0
Circuit breakers and fuses (EG000020) / Expulsion fuse-link, medium voltage (EC003611)
Rated current
8 A
Rated voltage
15000 V
Voltage type
AC
Rated frequency
45 - 62 Hz
Release characteristic
K
Type of termination
Double tail
Standard
ANSI
| Feature Name | Feature Value |
|---|---|
| Rated current (EF000227) | 8 A |
| Rated voltage (EF000228) | 15 kV |
| Voltage type (EF000187) | AC |
| Rated frequency (EF001663) | 50 Hz |
| Release characteristic (EF000889) | K |
| Type of termination (EF012540) | Double tail |
| Standard (EF009322) | ANSI |
