EATON - MOELLER 12KV 10Amp 2" 'A' DIN Fuse N/S 12KV 10Amp 2" 'A' DIN Fuse N/S 12SDLNA10 EATON ELECTRIC Fuse-link, LV, 10A, AC 690 V, NH000, gL/gG, IEC, dua.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

12KV 10Amp 2" 'A' DIN Fuse N/S 12SDLNA10 EATON ELECTRIC Fuse-link, LV, 10A, AC 690 V, NH000, gL/gG, IEC, dua..

12KV 10Amp 2" 'A' DIN Fuse N/S

12SDLNA10

EATON - MOELLER

3 Pcs.

Fuse-link, LV, 10A, AC 690 V, NH000, gL/gG, IEC, dual indicator, insulated gripping lugs 12KV 10Amp 2" 'A' DIN Fuse N/S 12KV 10Amp 2" 'A' DIN Fuse N/S - Fuse-link, medium voltage, 10 A, AC 12 kV, 2", 51 x 292 mm, back-up, DIN, no striker Fuse, Fuse-link, medium voltage, 10 A, AC 12 kV, 2z, 51 x 292 mm, back-up, DIN, indoor use

Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Engineered by Eaton Moeller, this 12KV 10Amp 2" 'A' DIN Fuse N/S acts as a reliable fuse-link for medium-voltage industrial installations. Industrial facilities rely on these components to protect primary transformer circuits from electrical faults and maintain overall grid stability.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated current (EF000227): 10 A
  • Rated voltage (EF000228): 12 kV
  • Voltage type (EF000187): AC
  • Rated frequency (EF001663): 50 Hz
  • Application (EF000041): Primary side transformer protection
  • Length (EF001438): 294 mm
  • Diameter (EF000551): 51 mm
  • Performance category according to IEC 60282-1 (EF012539): Back-up
  • With striker (EF008175): No
  • Standard (EF009322): DIN
  • Installation technique (EF001474): Air

More info

▲
Fuse-link, medium voltage, 10 A, AC 12 kV, 2", 51 x 292 mm, back-up, DIN, no striker
Fuse, Fuse-link, medium voltage, 10 A, AC 12 kV, 2", 51 x 292 mm, back-up, DIN, indoor use

Delivery program

Product range
Fuse
Basic function
Fuse-link
Field of application
medium voltage
Rated current [I]
10 A
Rated voltage
AC 12 kV
Construction size
2"
Size
51 x 292 mm
Utilization category
back-up
Status indicator
no striker
usable for size/applications
indoor use
Standard/Approval
DIN

Technical data ETIM 7.0

Circuit breakers and fuses (EG000020) / Medium-/high voltage fuse (EC003507)
Rated current
10 A
Rated voltage
12 kV
Voltage type
AC
Rated frequency
50 - 50 Hz
Breaking capacity
kA
Utilization category
Other
Application
Primary side transformer protection
Length
292 mm
Diameter
51 mm
Performance category according to IEC 60282-1
Back-up
With striker
No
Standard
DIN
Release characteristic
Other
Installation technique
Air
