View larger
Images are for illustrative purposes only. Please refer to data sheet for details
1.1KV 6.3A FUSE 1-1NBUNA6-3 1.1NBUNA6.3 EATON ELECTRIC VT fuse-link, medium voltage, 6.3 A, AC 1100 V, 86 x ..
1.1KV 6.3A FUSE
11NBUNA63
1.1NBUNA6.3
EATON - MOELLER
6 Pcs.
VT fuse-link, medium voltage, 6.3 A, AC 1100 V, 86 x 25.4 mm, back-up, BS, IEC
1.1KV 6.3A FUSE
Fuse, VT fuse-link, medium voltage, 6.3 A, AC 1100 V, 86 x 25.4 mm, back-up, BS, IEC, cylindrical, voltage and auxiliary transformers, BS2692-1, IEC 60282-1, Breaking Capacity 50 kA
Automation > Medium-/high voltage fuse
Bussmann Series Medium Voltage fuses and accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲VT fuse-link, medium voltage, 6.3 A, AC 1100 V, 86 x 25.4 mm, back-up, BS, IEC
Fuse, VT fuse-link, medium voltage, 6.3 A, AC 1100 V, 86 x 25.4 mm, back-up, BS, IEC, cylindrical, voltage and auxiliary transformers, BS2692-1, IEC 60282-1, Breaking Capacity 50 kA
General specifications
Product name
Eaton Bussmann series medium auxiliary fuse
Part no.
1-1NBUNA6-3
EAN
5027590427470
Product Length/Depth
86 millimetre
Product height
25.4 millimetre
Product width
25.4 millimetre
Product weight
120 gram
Compliances
Contact Manufacturer
Certifications
IEC
BS
BS
Product Tradename
None
Product Type
Medium voltage auxiliary fuse
Product Sub Type
None
Electrical data
Amperage Rating
6.3 A
Voltage rating
1.1 kV
Breaking capacity
50 kA
Performance Cat According To IEC 60282-1
Back-up
Class
Class back-up
Resistance
0.11 ohms
Product specifications
Application
Protection of auxiliary transformers
Fuse indicator
Non Indicating
Fuse size
86 x 25.4 mm
Standard
Other
| Feature Name | Feature Value |
|---|---|
| Rated current (EF000227) | 6.3 A |
| Rated voltage (EF000228) | 1.1 kV |
| Voltage type (EF000187) | AC |
| Breaking capacity (EF005617) | 50 kA |
| Utilization category according to IEC 60269 (EF002572) | Other |
| Application (EF000041) | Auxiliary transformer protection |
| Length (EF001438) | 86 mm |
| Performance category according to IEC 60282-1 (EF012539) | Back-up |
| With striker (EF008175) | No |
| Standard (EF009322) | Other |
| Release characteristic (EF000889) | Other |
| Installation technique (EF001474) | Air |
