EATON - MOELLER CH221DMSU-F CH221DMSU-F EATON ELECTRIC Fuse switch-disconnector, 100A, 3p, 22x58 size View larger
Images are for illustrative purposes only. Please refer to data sheet for details

CH221DMSU-F EATON ELECTRIC Fuse switch-disconnector, 100A, 3p, 22x58 size

CH221DMSU-F

CH221DMSUF

EATON - MOELLER

6 Pcs.

1P 22x58 Micro Switch Fuse Holder Eaton's Bussmann series 1-Pole modular fuse holder, rated at 690 V a.c./1000 V d.c. (IEC), 700 V a.c. (UL) , 125 Amps (IEC), 100 A (UL), fitted with a microswitch, suitable for 22 x 58 mm Cylindrical fuses Fuse accessory, Fuse-holder, low voltage, 125 A, AC 690 V, 22 x 58 mm, 1P, IEC, UL, with microswitch, C22M and C22G fuses, IEC 60269-1, IEC 60269-2, IP20

Automation > Holder for cylindrical fuse
Bussmann Series Low Voltage fuses and accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Eaton Moeller CH221DMSU-F fuse switch-disconnector combines physical circuit isolation with cylindrical fuse housing to protect heavy electrical loads. Industrial setups rely on these switch-disconnectors to safely interrupt load currents and prevent electrical faults. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Nominal voltage (EF000002): 690 V
  • Mounting method (EF000003): DIN rail
  • For fuse size (EF008316): 22x58 mm
  • Number of poles (EF001391): 1
  • Concurrently switching neutral conductor (EF005997): No
  • Lockable (EF000113): Yes
  • With optical defect indication (EF008181): No
  • Width in number of modular spacings (EF002950): 2
  • Built-in depth (EF000218): 51.5 mm
  • Degree of protection (IP) (EF005474): IP20

More info

▲

General specifications

Product Name
Eaton Bussmann series low voltage cylindrical fuse holder
Catalog Number
CH221DMSU-F
Model Code
1P 22x58 Micro Switch Fuse Holder
EAN
5027590496995
UPC
051712685337
Product Length/Depth
77 mm
Product Height
123 mm
Product Width
36 mm
Product Weight
184.167 g
Compliances
CE Marked
RoHS Compliant
Certifications
IEC 60269-2
EAC
IEC 60269-1
UL Listed File E14853

Electrical data

Amperage Rating
125 A
Voltage rating at AC
690 V a.c. (IEC) and 700 V a.c. (UL)
Voltage rating at DC
1000 V d.c. (IEC)

Product specification

Number of Poles
Single-pole
Mounting method
DIN rail
2 x M4 Panel mounting screws
Optical defect indication
No
Fitted with:
microswitch
Degree of protection
IP20
Built-in depth
51.5 mm
Lockable
Yes
Width in number of modular spacings
2
Application
Industrial and Commercial applications

Compatible fuse

Fuse size
22 x 58 mm
Fuse type
C22G
C22M

Accessories

Accessories
JV-L Multipole connector kit, CH22-CTP IP20 Protection accessory

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
