CARLO GAVAZZI SPD12601B SPD12601B CARLO GAVAZZI Selected parameters MODEL Din Rail AC INPUT VOLTAGE 85 264V OUTPUT POWER 60W PARALLE.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SPD12601B CARLO GAVAZZI Selected parameters MODEL Din Rail AC INPUT VOLTAGE 85 264V OUTPUT POWER 60W PARALLE..

SPD12601B

12601

CARLO GAVAZZI

1 Pcs.

Selected parameters MODEL Din Rail AC INPUT VOLTAGE 85 - 264V OUTPUT POWER 60W PARALLEL CONNECTION no INPUT TYPE Single phase or DC OUTPUT VOLTAGE 12Vdc PFC no DC INPUT VOLTAGE 90 - 375V TERMINAL TYPE Spring terminal OUTPUT RDY no Others DESCRIPTION 60W, Spring terminals Single-phase power supply, output 12Vdc, output current 5 A, output power 60 W Switching Power Supply, AC/DC, 60W, 12V, Spring Terminals, IP20, DIN-Rail Mounting, Over-load, Over-voltage and Short-circuit Protections, 40.5x90x114mm housing

Automation > DC-power supply

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A SPD12601B CARLO GAVAZZI Selected parameters MODEL Din Rail AC INPUT VOLTAGE 85 264V OUTPUT POWER 60W PARALL.. is a switched-mode power supply designed to convert alternating current mains inputs into stable direct current outputs for industrial control panels and automation equipment. Power supplies of this type provide reliable, regulated voltage to sensors, actuators, and logic controllers within automated systems.

Final pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Voltage type (supply voltage) (EF002991): AC/DC
  • 1st secondary output voltage (EF006792): 11.94 V
  • 2nd secondary output voltage (EF006797): 0 V
  • 3rd secondary output voltage (EF006800): 0 V
  • Max. output current 1 (EF008284): 5 A
  • Max. output current 2 (EF008285): 0 A
  • Max. output current 3 (EF008286): 0 A
  • Secondary voltage adjustable (EF007002): Yes
  • Nominal value output voltage 1 (EF009393): 12 V
  • Nominal value output voltage 2 (EF009394): 0 V
  • Nominal value output voltage 3 (EF009395): 0 V
  • Nominal value output current 1 (EF009396): 5 A
  • Nominal value output current 2 (EF009397): 0 A
  • Nominal value output current 3 (EF009398): 0 A
  • Short-circuit-proof (EF007332): Yes
  • Rated supply voltage AC 50 Hz (EF007076): 100 V

More info

▲

Specifications

Rated output voltage DC
12 V
Power output
60 W
Max. output current DC
5 A
Terminal type
Spring clamp connection
Rail mounting possible
Yes
Wall mounting possible
No
Degree of protection (IP)
IP20
Width
40.5 mm
Height
90 mm
Depth
114 mm

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
