> CARLO GAVAZZI > 48301
CARLO GAVAZZI SPD48301 SPD48301 CARLO GAVAZZI Selected parameters MODEL Din Rail AC INPUT VOLTAGE 85 264V OUTPUT POWER 30W PARALLEL.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SPD48301 CARLO GAVAZZI Selected parameters MODEL Din Rail AC INPUT VOLTAGE 85 264V OUTPUT POWER 30W PARALLEL..

SPD48301

48301

CARLO GAVAZZI

1 Pcs.

Selected parameters MODEL Din Rail AC INPUT VOLTAGE 85 - 264V OUTPUT POWER 30W PARALLEL CONNECTION no INPUT TYPE Single phase or DC OUTPUT VOLTAGE 48Vdc PFC no DC INPUT VOLTAGE 90 - 375V TERMINAL TYPE Screw terminal OUTPUT RDY no Others DESCRIPTION 30W, Screw terminals Switching Power Supply, Din Rail Mounting, Output Voltage 48 Vdc Switching Power Supply, AC/DC, 30W, 48V, Screw Terminals, IP20, DIN-Rail Mounting, Over-load, Over-voltage and Short-circuit Protections, 40.5x90x114mm housing

Automation > DC-power supply

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The SPD48301 Carlo Gavazzi selected parameters model din rail ac input voltage 85 264v output power 30w parallel.. functions as a DIN-rail mountable power supply unit built to transform standard alternating or direct current inputs into regulated 48V DC power. Such power modules are routinely utilized in industrial automation to support specialized drives and communication hardware.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Voltage type (supply voltage) (EF002991): AC/DC
  • 1st secondary output voltage (EF006792): 47.76 V
  • 2nd secondary output voltage (EF006797): 0 V
  • 3rd secondary output voltage (EF006800): 0 V
  • Max. output current 1 (EF008284): 0.625 A
  • Max. output current 2 (EF008285): 0 A
  • Max. output current 3 (EF008286): 0 A
  • Secondary voltage adjustable (EF007002): Yes
  • Nominal value output voltage 1 (EF009393): 48 V
  • Nominal value output voltage 2 (EF009394): 0 V
  • Nominal value output voltage 3 (EF009395): 0 V
  • Nominal value output current 1 (EF009396): 0.625 A
  • Nominal value output current 2 (EF009397): 0 A
  • Nominal value output current 3 (EF009398): 0 A
  • Short-circuit-proof (EF007332): Yes
  • Rated supply voltage AC 50 Hz (EF007076): 100 V

More info

▲

Specifications

Rated output voltage DC
48 V
Power output
30 W
Max. output current DC
0.625 A
Terminal type
Screw connection
Rail mounting possible
Yes
Wall mounting possible
No
Degree of protection (IP)
IP20
Width
40.5 mm
Height
90 mm
Depth
114 mm

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
