View larger
Images are for illustrative purposes only. Please refer to data sheet for details
EM21072DAV63XOXX CARLO GAVAZZI Selected parameters FUNCTION Energy analyzer MOUNTING DIN-rail and Panel POWE..
EM21072DAV63XOXX
21072
CARLO GAVAZZI
1 Pcs.
Selected parameters FUNCTION Energy analyzer MOUNTING DIN-rail and Panel POWER SUPPLY Self power supply OUTPUT DIGITAL INPUT DC/AC output (Opto Mosfet) INPUT TYPE 3-phase AC CONNECTION CT/VT Others RANGE 120VLN/230VLL AC 5(6)A or 1(6)A DISPLAY 6+1 DGT VARIABLES W, var, PF, Hz, Phase-sequence DIGITAL INPUTS none PULSE 1 ALARMS none ANALOGUE none
Three-phase electric power meter, Removable display, Current input /5A
Three-phase Energy analyzer, 57.7 to 144 V L-N, 100 to 230 V L-L, 5 (6) A, Pulse output
Automation > Kilowatt-hour meter
Digital Panel Meters and temperature
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Specifications
Voltage inputs
1-phase (2-wire), 115 V L-N; 1-phase (2-wire), 120 V L-N; 2-phase (3-wire), 110/220 V; 2-phase (3-wire), 115/230 V; 3-phase (4-wire), 120/208 V; 3-phase (4-wire), 127/220 V
Frequency
50Hz; 60Hz
Current inputs
5 A current transformers
Energy metering
Consumption and generation
Power supply
Self power supply
Approvals, marks, declarations
CE (Europe); cULus (North America); UKCA (UK)
| Feature Name | Feature Value |
|---|---|
| Type of meter (EF005441) | Electronic |
| Nominal current (In) (EF008873) | 5 A |
| Max. current (Imax) (EF000877) | 6 A |
| Nominal voltage (Un) N-L (EF008871) | 57.7 V |
| Nominal voltage (Un) L-L (EF008872) | 100 V |
| Frequency (EF000416) | 50 Hz |
| Pole type (EF008843) | Three conductor/four conductor |
| Model (EF000010) | Measurement transformer |
| Energy type (EF007135) | Effective power and reactive power |
| Suitable for (EF000073) | Purchase/supply |
| Calibrated (EF008836) | Yes |
| Pulse output (EF008838) | Optic |
| Pulse rate (EF008840) | 10 Imp/kWh (kvarh) |
| Type of indication (EF000306) | Digital |
| Mounting method (EF000003) | DRA (DIN-rail adapter) |
| Width in number of modular spacings (EF002950) | 4 |
| With lock code (EF008846) | Yes |
| Number of positions total (counter) (EF004442) | 7 |
| Degree of protection (IP) (EF005474) | IP40 |
