View larger
Images are for illustrative purposes only. Please refer to data sheet for details
RA23110H06PCS CARLO GAVAZZI Ssr Sense Zs 230V 110Apnp
RA23110H06PCS
23110
CARLO GAVAZZI
1 Pcs.
Ssr Sense Zs 230V 110Apnp
Solid State Relays
1-pole panel mount SSR, Zero-cross switching with system monitoring and normally closed PNP alarm output, Operating voltage (Ue): 170 - 250 Vac (650 Vp), Rated current (Ie): 110 Aac, Control voltage (Uc): 7 - 32 Vdc, External supply: 20 - 32 Vdc
Automation > Solid state relay
Solid state relays
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Specifications
Output switching mode
Zero cross
Number of poles
1
Rated current AC-51
110 A
Rated current AC-53a
30 A
Operating voltage
170 V ... 250 V
Control voltage DC
20 V ... 32 V
Power connection
Screw
| Feature Name | Feature Value |
|---|---|
| Rated control supply voltage DC (EF003980) | 20 V |
| Voltage type for actuating (EF008242) | DC |
| Rated operation current Ie at AC-51 (EF009488) | 110 A |
| Rated operation current Ie at AC-53a (EF009489) | 30 A |
| Number of phases (EF000351) | 1 |
| Modular version (EF001126) | No |
| Switching at zero-crossing (EF011956) | Yes |
