View larger
Images are for illustrative purposes only. Please refer to data sheet for details
DIB02CD48150MV CARLO GAVAZZI Control relay single phase current max. or min. AC/DC, TRMS, Power supply 24 to..
DIB02CD48150MV
48150
CARLO GAVAZZI
1 Pcs.
Control relay single phase current max. or min. AC/DC, TRMS, Power supply 24 to 48 VAC/DC
Single-phase control relay max. or min AC/DC intensity, TRMS, Power supply 24 to 48 VAC/DC
1-phase AC/DC over or undercurrent monitoring relay, input range 0.5-500 A AC, SPDT relay output, 22.5 mm DIN-rail housing
Automation > Current monitoring relay
Monitoring Relays and Measurement Current Transformers
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Specifications
Rated supply voltage
24-48 V AC/DC
Mounting
Industrial DIN-rail
AC/DC current function
Overcurrent; Undercurrent; Over or undercurrent
1/3-phase current category
Above 5 A
Output
1 relay
Time delay
Delay on alarm
| Feature Name | Feature Value |
|---|---|
| Type of electric connection (EF003961) | Screw connection |
| With detachable clamps (EF003340) | No |
| Single-phase under current possible (EF003405) | No |
| Three-phase under current possible (EF003406) | No |
| Single-phase overcurrent possible (EF003407) | Yes |
| Single-phase hysteresis possible (EF003394) | Yes |
| Current measuring range (EF000417) | 0.5 A |
| Min. adjustable delay-on energization time (EF008190) | 0.1 s |
| Max. permitted delay-on energization time (EF008189) | 30 s |
| External current transformer (EF001923) | Yes |
| Width (EF000008) | 22.5 mm |
| Height (EF000040) | 80 mm |
| Depth (EF000049) | 99.5 mm |
