BTICINO YG4301A10 YG4301A10 BTCINO LW-MAG 1P+N 10A 1M ST View larger
Images are for illustrative purposes only. Please refer to data sheet for details

YG4301A10 BTCINO LW-MAG 1P+N 10A 1M ST

YG4301A10

YG4301A10

BTICINO

1 Pcs.

LW-MAG 1P+N 10A 1M ST Light Now automatic circuit breaker - 10A - 1 module - Stone

Automation > Miniature circuit breaker (MCB)
MATIX MECHANISMS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A Bticino YG4301A10 miniature circuit breaker provides dependable electrical protection by automatically interrupting circuits during fault conditions. These modular devices are commonly deployed in building distribution panels to secure single-phase lines and neutral conductors.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Explosion-proof: No
  • Connectable conductor cross section solid-core: 2.5 mm²
  • Ambient temperature during operating: -5 °C
  • Degree of protection (IP): IP20
  • Concurrently switching neutral conductor: Yes
  • Voltage type: AC
  • Additional equipment possible: No
  • Rated impulse withstand voltage Uimp: 4 kV
  • Number of protected poles: 1
  • Frequency: 50 Hz
  • Built-in depth: 40 mm
  • Number of poles (total): 1
  • Width in number of modular spacings: 22.5
  • Rated insulation voltage Ui: 253 V
  • Connectable conductor cross section multi-wired: 1.5 mm²
  • Rated current: 10 A

More info

▲
Automatic circuit breakers - It has a protected pole - Open and closed contact indicator - 10A - Breaking power: 3,000A - 1 module - Stone.
Installation Depth40 mm
Shot curveC
Number of poles (total)1
Number of protected poles1
Nominal current10 A
Nominal voltage230 V
Nominal insulation voltage Ui253 V
Assigned Voltage Peak Resistance (Uimp)4 kV
Type of voltageAC
frequency50-60 Hz
Power Limitation Class1
Flush mountingYes
Neutral Conductor CouplingYes
Additional equipment possibleNo
Width in number of modular spaces22.5
Protection Class (IP)IP20
Ambient temperature during operation-5-35 °C
Connectable conductor section1.5-2.5 mm²
Solid Connectable Conductor Section2.5-3 mm²
Explosion protectionNo
Width22.5 mm
Height45 mm
Depth50 mm
Impact resistanceIK04
Storage temperature-10-70 °C
Nominal Voltage110-230 V
Direction of the electricity supplyOn the back of the product
Display of markings on the connection terminalsNo
ColourGrey
RAL number7008
Halogen-freeYes
Connection MethodScrew-on terminal
Connection typeOther
Label Space/Print AreaNo
Type of mountingRecessed mounted (plaster)
