Y4380 BTCINO LW-AUTO LED FLASHLIGHT 230V 2M
Y4380
Y4380
BTICINO
1 Pcs.
Automation > Emergency luminaire
MATIX MECHANISMS
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Built-in LED emergency flashlights, such as the Bticino Y4380 LW-AUTO LED FLASHLIGHT 230V 2M, offer integrated illumination modules that activate during grid failures to assist personnel in navigating dark spaces or locating electrical panels. Such modular safety devices install directly into standard electrical enclosures.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Conductor cross section (EF000085): 1.5 mm²
- With remote control (EF000483): No
- Lamp type (EF002423): LED non-replaceable
- Mounting method (EF000003): Built-in
- Connection type (EF000124): Screw connection
- RAL-number housing (EF012502): 9003
- Material cover (EF004284): Plastic opal
- Built-in height/depth (EF023518): 45 mm
- With remote switch connection (EF007947): No
- Colour temperature (EF009346): 4000 K
- Recognition distance (EF008732): 5 m
- Suitable for number of light sources (EF006436): 2
- Number of lighting heads (EF004258): 1
- Impact strength (EF004293): IK04
- Height/depth (EF001456): 45 mm
- With pictogram (EF011099): No
More info
▲| Type of mounting | Installation |
|---|---|
| function | Escape route lighting |
| Suitable for labelling type | Other |
| Type of indicator | One side |
| With pictogram | No |
| Suitable for standby switching | No |
| Suitable for continuous circuit | Yes |
| With remote switch connection | No |
| With remote control | No |
| Emergency function monitoring system | none |
| Emergency Power Supply System | Peripheral unit (single battery) |
| Battery quality | Nimh |
| Lamp | Non-interchangeable LED |
| With light source | Yes |
| Suitable for number of light sources | 2 |
| Lamp holder | none |
| Number of light heads | 1 |
| Housing material | Plastic |
| RAL number of the case | 9003 |
| Housing color | Grey |
| Cover material | Plastic, opal |
| Type of voltage | AC |
| Nominal Voltage | 110-230 V |
| Type of control equipment | Not required |
| Interchangeable control equipment | No |
| Light distributor | Lens/Optics/Diffuser Panel |
| Energy efficiency class according to EU2019/215 | to |
| Constant luminous flux regulation | No |
| Protection Class (IP) | IP30 |
| Degree of protection (NEMA) | Other |
| Impact resistance | IK04 |
| Protection class according to IEC 61140 | none |
| Luminaire with limited surface temperature "mark D" according to EN 60598-2-24 | No |
| Rated ambient temperature according to IEC 62722-2-1 | -5-35 °C |
| Nominal luminous flux according to IEC 62722-2-1 | 0-0 lm |
| Color Temperature | 4000-5500 K |
| Reconnaissance distance | 5 m |
| Nominal Operating Time | 2-2 hrs |
|---|---|
| Width | 45 mm |
| Height/Depth | 45 mm |
| Longitude | 44.5 mm |
| Mounting width | 45 mm |
| Mounting height/depth | 45 mm |
| Installation Length | 33 mm |
| Type of wiring | Terminal |
| Conductor cross-section | 1.5 mm² |
| Connection Method | Threaded connection |
| Connectable conductor cross-section | 1.5-2.5 mm² |
| Operating Temperature | -5-35 °C |
| Storage temperature | -10-70 °C |
| frequency | 50-60 Hz |
| Neutral Mandatory | No |
| Display of markings on the connection terminals | No |
| Halogen-free | Yes |
| Connection Cable Type | Flexible or rigid |
| With signal lamp | No |
| Distance between vertical clamping centers | 3.5-3.7 mm |
| Distance between horizontal clamping centers | 3-3.2 mm |
| Cable Holder | Cable glands |
| Cable tie compatible with | All Conduit/Cable Types |
| Control Mode | Not applicable |
| Contains battery and/or accumulator | Yes |
| Addressable | No |
| Battery or accumulator (Pack1) | Accumulator (rechargeable) |
| Item Composition (Pack1) | Nickel metal hydride |
| Battery or accumulator (Pack2) | Not applicable |
| Item Composition (Pack2) | Not applicable |
| Connected Object | No |
| Programming medium | Not applicable |
| With voice command | No |
| Programmable | No |
| Connection Protocol Interoperability | No |
| Possibility of connection via Internet box | No |
| Product usage function | Emergency lighting |
