R4380 BTCINO CL-FLASHLIGHT AUTO LED 230V 2M
R4380
R4380
BTICINO
1 Pcs.
CL-FLASHLIGHT AUTO LED 230V 2M
Classia LED Removable Autonomic Flashlight - 2 modules
Classia Standalone LED Removable Flashlight - 2mod
Automation > Emergency luminaire
classia mechanisms
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Product features
Acoustic and light signaling - Signaling lamps - LED 230 V~ of high luminosity - Autonomous operation in the event of a possible power cut - Autonomy of 2 h - Includes recharge base - 2 Ni-Cd batteries - 2 modules - Led white light of high luminous efficiency - ON/OFF switch and SPOT button to increase the luminosity when necessary - Replaceable Ni-MH batteries without memory effect - 2 modules - To be combined with support and beautifying plate - It includes fronts in white and dark finishes.General features
Classia - acoustic and light signalling| Feature Name | Feature Value |
|---|---|
| Lamp type (EF002423) | LED non-replaceable |
| Mounting method (EF000003) | Built-in |
| RAL-number housing (EF012502) | 9003 |
| Material cover (EF004284) | Plastic opal |
| Built-in height/depth (EF023518) | 33.2 mm |
| With remote switch connection (EF007947) | No |
| Recognition distance (EF008732) | 3 m |
| Monitoring equipment (EF008091) | None |
| Protection class according to IEC 61140 (EF000004) | None |
| Height/depth (EF001456) | 43 mm |
| Width (EF000008) | 44 mm |
| Built-in width (EF000846) | 44 mm |
| Built-in length (EF004265) | 44 mm |
| Degree of protection (IP) (EF005474) | IP20 |
| Voltage type (EF000187) | AC |
| Housing colour (EF000136) | White |
| Function (EF000030) | Escape route lighting/signage |
| Nominal voltage (EF005127) | 110 V |
| Power supply system (EF000233) | Central (central battery) |
| Battery technology (EF004351) | NiMH |
| Nominal operation time (EF012518) | 2 h |
| Length (EF001438) | 44 mm |
| Suitable for continuous circuit (EF017056) | Yes |
