View larger
Images are for illustrative purposes only. Please refer to data sheet for details
KM41 BTCINO LNWN COMMAND KEY D/N 1M SAND
KM41
KM41
BTICINO
10 Pcs.
LNWN COMMAND KEY D/N 1M SAND
2P+T Living Now Base - Italian standard - screw connection - Sand - 1 module
Living Now w/Netatmo key for wireless command "Day/Night" - Sand - 1mod
Automation > Control element/cover plate for domestic switching devices
LIVING NOW WITH NETATMO
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲
Italian standard 2P+T bases - 10A - 250 Vac - Distance between alveoli of 19mm - Screw connection - With protection shutters - 1 module -To be combined with KM02 front, support and decorative plate - Sand.
| Model | Italian Type P11 |
|---|---|
| Protective contact | Round |
| Number of active (round) contacts | 1 |
| Number of active contacts (drawings) | 0 |
| Type of mounting | Basic element with center cover plate, Recessed mounted (plaster) |
| With signal lamp | No |
| Number of USB-A ports | 0 |
| Number of USB-C ports | 0 |
| Number of sockets | 1 |
| Phase-separated power outlets | No |
| Number of modules (in case of modular design) | 1 |
| Number of interchangeable sockets | 0 |
| Number of phases | 1 |
| Printing/Marking | Other |
| Connection Method | Screw-on terminal |
| With flip-top lid | No |
| With enhanced contact protection | Yes |
| Label Space/Print Area | No |
| Colour | Beige |
| RAL number (similar) | 1013 |
| Metallic color | No |
| Transparent | No |
| Lockable | No |
| Expulsion mechanism | No |
| Isolated installation | No |
| With functional lighting | No |
| With adjustable lighting | No |
| Surge protection | No |
| Residual Current Device | No |
| With microfusion | No |
| Special power supply | none |
| Attachment Type | Hemming |
| Material | Plastic |
| Material quality | Thermoplastic |
| Halogen-free | Yes |
|---|---|
| Surface treatment | No treatment |
| Surface Finish | Mate |
| Antibacterial treatment | No |
| With loop function | No |
| With on/off switch | No |
| Rotated center insert | No |
| Nominal intensity | 10 A |
| Nominal Voltage | 250 V |
| frequency | 45-55 Hz |
| Suitable for protection grade (IP) | IP20 |
| Impact resistance | Other |
| Device width | 22 mm |
| Device height | 45 mm |
| Device Depth | 38 mm |
| Min. depth of the recessed box | 38 mm |
| Compatible with Apple HomeKit | No |
| Compatible with Amazon Alexa | No |
| Compatible with Google Assistant | No |
| Compatible IFTTT | No |
| With Wi-Fi signal repeater | No |
| With built-in bluetooth speaker | No |
| For server conditions according to VDE | No |
| Installation Depth | 28 mm |
| Operating Temperature | -5-35 °C |
| Storage temperature | -5-35 °C |
| Type of voltage | AC |
| Power Delivery | No |
| Prewired | No |
| Terminal capacity | 2.5-4 mm² |
| Connection Cable Type | Flexible or rigid |
| Core cross-section | 2.5-4 mm² |
| Cable Holder | Cable glands |
| Connected Object | No |
| Feature Name | Feature Value |
|---|---|
| Height (EF000040) | 86 mm |
| RAL-number (similar) (EF003882) | 1015 |
| Model (EF000010) | One-part rocker |
| Suitable for touch sensor connector for bus system (EF007802) | No |
| Material (EF002169) | Plastic |
| Utilization (EF000133) | Switch/push button |
| Monitoring window/light outlet (EF003864) | Yes |
| Surface finishing (EF006569) | Matt |
| Type of fastening (EF002442) | Engage (snap) |
| Material quality (EF001257) | Thermoplastic |
| Halogen free (EF000025) | Yes |
| With exchangeable lens/symbol (EF006039) | No |
| With label area (EF005040) | No |
| Scannable symbol/barrier free (EF012306) | No |
| Anti-bacterial treatment (EF023790) | No |
| Impact strength (EF004293) | IK04 |
| Imprint/indication (EF003823) | Various symbols |
| Depth (EF000049) | 7 mm |
| Colour (EF000007) | Beige |
| Surface protection (EF000139) | Untreated |
| Width (EF000008) | 22 mm |
