BTICINO KG41 KG41 BTCINO LNWN COMMAND KEY D/N 1M DARK View larger
Images are for illustrative purposes only. Please refer to data sheet for details

KG41 BTCINO LNWN COMMAND KEY D/N 1M DARK

KG41

KG41

BTICINO

10 Pcs.

LNWN COMMAND KEY D/N 1M DARK 2P+T Living Now Base - Italian Standard - Screw Connection - Dark - 1 Module Living Now w/Netatmo key for wireless command "Day/Night" - Dark - 1mod

Automation > Control element/cover plate for domestic switching devices
LIVING NOW WITH NETATMO

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A Bticino KG41 one-part rocker serves as a multi-symbol command key for day and night operational switching modes in building installations.

These rocker inserts snap into standard frames to deliver distinct manual control options for automated facility management networks.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Height (EF000040): 86 mm
  • RAL-number (similar) (EF003882): 7015
  • Model (EF000010): One-part rocker
  • Material (EF002169): Plastic
  • Utilization (EF000133): Switch/push button
  • Monitoring window/light outlet (EF003864): Yes
  • Surface finishing (EF006569): Matt
  • Type of fastening (EF002442): Engage (snap)
  • Material quality (EF001257): Thermoplastic
  • Halogen free (EF000025): Yes
  • With exchangeable lens/symbol (EF006039): No
  • With label area (EF005040): No
  • Scannable symbol/barrier free (EF012306): No
  • Anti-bacterial treatment (EF023790): No
  • Impact strength (EF004293): IK04
  • Imprint/indication (EF003823): Various symbols

More info

▲
Italian standard 2P+T bases - 10A - 250 Vac - Distance between alveoli of 19mm - Screw connection - With protection shutters - 1 module -To be combined with KG02 front, support and decorative plate - Dark.
ModelItalian Type P11
Protective contactRound
Number of active (round) contacts1
Number of active contacts (drawings)0
Type of mountingBasic element with center cover plate, Recessed mounted (plaster)
With signal lampNo
Number of USB-A ports0
Number of USB-C ports0
Number of sockets1
Phase-separated power outletsNo
Number of modules (in case of modular design)1
Number of interchangeable sockets0
Number of phases1
Printing/MarkingOther
Connection MethodScrew-on terminal
With flip-top lidNo
With enhanced contact protectionYes
Label Space/Print AreaNo
ColourBlack
RAL number (similar)7015
Metallic colorNo
TransparentNo
LockableNo
Expulsion mechanismNo
Isolated installationNo
With functional lightingNo
With adjustable lightingNo
Surge protectionNo
Residual Current DeviceNo
With microfusionNo
Special power supplynone
Attachment TypeHemming
MaterialPlastic
Material qualityThermoplastic
Halogen-freeYes
Surface treatmentNo treatment
Surface FinishMate
Antibacterial treatmentNo
With loop functionNo
With on/off switchNo
Rotated center insertNo
Nominal intensity10 A
Nominal Voltage250 V
frequency45-55 Hz
Suitable for protection grade (IP)IP20
Impact resistanceOther
Device width22 mm
Device height45 mm
Device Depth38 mm
Min. depth of the recessed box38 mm
Compatible with Apple HomeKitNo
Compatible with Amazon AlexaNo
Compatible with Google AssistantNo
Compatible IFTTTNo
With Wi-Fi signal repeaterNo
With built-in bluetooth speakerNo
For server conditions according to VDENo
Installation Depth28 mm
Operating Temperature-5-35 °C
Storage temperature-5-35 °C
Type of voltageAC
Power DeliveryNo
PrewiredNo
Terminal capacity2.5-4 mm²
Connection Cable TypeFlexible or rigid
Core cross-section2.5-4 mm²
Cable HolderCable glands
Connected ObjectNo
