Images are for illustrative purposes only. Please refer to data sheet for details
667232 4TQA667232R0000 AEG EP60 1P 10A C
667232
667232
AEG
1 unit
Automation > Tertiary
Tertiary
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteMore info
▲- Extended Product Type:
- EP61 C10
- Product ID:
- 4TQA667232R0000
- EAN:
- 5411815225543
- Catalog Description:
- EP61 C10 Miniature Circuit Breaker - 1P - C - 10 A
- Long Description:
- The EP MCB Series (6 kA to 25 kA) are intended for circuit protection (overload and short circuits), conforming 60898-1, 60947-2 Standards
Eco Transparency
- Environmental Product Declaration - EPD:
- 9AKK108468A0273
Technical
- Standards:
- IEC/EN 60898-1
60947- 2
- Tripping Characteristic:
- C
- Rated Operational Voltage:
- 230 / 400 V AC
acc. to IEC 60898-1 230 V
- Rated Insulation Voltage (Ui):
- acc. to IEC/EN 60664-1 440 V
- Rated Impulse Withstand Voltage (Uimp):
- 6 kV
- Input Voltage Type:
- AC
- Rated Current (In):
- 10 A
- Rated Short-Circuit Capacity:
- (230 V AC) 6 kA
(400 V AC) 6 kA
(230 V) 6 kA
- Rated Ultimate Short-Circuit Breaking Capacity (Icu):
- (230 V) 10 kA
(400 V) 3 kA
- Rated Frequency (f):
- 50 / 60 Hz
- Energy Limiting Class:
- 3
- Number of Protected Poles:
- 1
- Number of Poles:
- 1
- Accessories Available:
- Yes
- Connecting Capacity:
- Flexible 0.75 ... 25 mm²
Rigid 1 ... 35 mm²
Environmental
- Ambient Air Temperature:
- Operation -25 ... +55 °C
- Degree of Protection:
- IP20
- Pollution Degree:
- 3
- RoHS Status:
- Following EU Directive 2011/65/EU
- REACH Declaration:
- No declaration needed
- Conflict Minerals Reporting Template (CMRT):
- 9AKK108468A3363
Dimensions
- Width in Number of Modular Spacings:
- 1
- Product Net Width:
- 18mm
- Product Net Height:
- 70mm
- Product Net Depth / Length:
- 91mm
- Product Net Weight:
- 0.128kg
- Built-In Depth (t2):
- 70 mm
Ordering
- Package Level 1 Units:
- carton 12 piece
- Package Level 1 Gross Weight:
- 1.576 kg
Certificates and Declarations
- Certification Agency:
- EN
Classifications
- ETIM 8:
- EC000042 - Miniature circuit breaker (MCB)
- ETIM 9:
- EC000042 - Miniature circuit breaker (MCB)
- WEEE Category:
- 5. Small Equipment (No External Dimension More Than 50 cm)
- WEEE B2C / B2B:
- Business To Business
- CN8:
- 8536 20 10
- UNSPSC:
- 39121603
- eClass:
- V11.0 : 27141901
- IDEA Granular Category Code (IGCC):
- 4897 >> Miniature circuit breakers
- Object Classification Code:
- Q
