1SFN166521R1070 ABB ZP1650 Circuit Board
1SFN166521R1070
166521
ABB
1 Pcs.
Automation > Accessories/spare parts for low-voltage switch technology
connectors
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Circuit boards in industrial control gear manage internal logic routing, signaling, and power regulation for heavy-duty switching hardware. The ABB replacement circuit board restores proper electronic functionality to compatible block contactors.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85389099
- Data Sheet, Technical Information: 1SBC100214C0202
- Instructions and Manuals: 1SFC101002M5501
- CAD Dimensional Drawing: 2CDC001079B0201
- Product Net Width: 120 mm
- Product Net Depth / Length: 25 mm
- Product Net Height: 200 mm
- Product Net Weight: 0.3 kg
- Terminal Type: Screw Terminals
- Suitable For: AF1350
- Suitable for Product Class: Block Contactors
- Product Name: Circuit Board
- Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
- REACH Declaration: 2CMT2021-006202
- RoHS Declaration: 2CMT2021-006277
More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389099 |
| Popular Downloads | |
| Data Sheet, Technical Information | 1SBC100214C0202 |
| Instructions and Manuals | 1SFC101002M5501 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Dimensions | |
| Product Net Width | 120 mm |
| Product Net Depth / Length | 25 mm |
| Product Net Height | 200 mm |
| Product Net Weight | 0.3 kg |
| Technical | |
| Terminal Type | Screw Terminals |
| Suitable For | AF1350 |
| AF1650 | |
| AF2050 | |
| GAF1650 | |
| GAF2050 | |
| Suitable for Product Class | Block Contactors |
| Product Name | Circuit Board |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2021-006202 |
| RoHS Declaration | 2CMT2021-006277 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006525 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 2CMT005309 |
| Declaration of Conformity - UKCA | 2CMT2020-006120 |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 125 mm |
| Package Level 1 Depth / Length | 67 mm |
| Package Level 1 Height | 278 mm |
| Package Level 1 Gross Weight | 0.3 kg |
| Package Level 1 EAN | 7320500250853 |
| External Classifications and Standards | |
| Object Classification Code | M |
| ETIM 7 | EC002498 - Accessories for low-voltage switch technology |
| ETIM 8 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| ETIM 9 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| UNSPSC | 32131010 |
| IDEA Granular Category Code (IGCC) | 3503 >> Bare printed circuit boards |
| E-Number (Norway) | 4121061 |
| E-Number (Sweden) | 4121061 |
