View larger
Images are for illustrative purposes only. Please refer to data sheet for details
1SDA068199R1 ABB XT4 P FP 4p HR
1SDA068199R1
068199
ABB
1 Pcs.
XT4 P FP 4p HR
4P THERMAL PLUG-IN BASE. HR P FP-XT4
Automation > Chassis part power circuit breaker
Molded Case Circuit Breakers ≤ 250 A Xtmax
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| Circular Value | |
|---|---|
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Information | 9AKK108466A1424 |
| RoHS Status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | ee4dc2f8-c498-495d-ab3c-2fb33661233a Italy (IT) |
| Simplified SCIP | 8c449a64-3406-4146-b38c-4b70ed940051 Germany (DE) |
| 95877e32-97f1-4140-91ff-4e407972c1b8 Sweden (SE) | |
| aaec441b-5d77-4fc5-aed4-44324653dcd6 Poland (PL) | |
| 12892faa-41fb-4ce3-b45e-0e7c2ac6d7e2 France (FR) | |
| c412b901-5ee6-4bda-905a-3e27b79b26b7 Sweden (SE) | |
| 6cb0acf4-c047-43b4-a818-b7e71c4649ea Germany (DE) | |
| 71572dc3-6300-43c7-97d4-603947c3a556 Germany (DE) | |
| 58790733-1af2-4f75-911d-bc01ec3b11a0 France (FR) | |
| 660b3738-9039-4667-8bea-c61fdd829593 Netherlands (NL) | |
| f7d78e6d-d9a4-4a52-9f7b-f38b4fd5ab8b Spain (ES) | |
| 0bd5cdce-e056-4496-8120-7c416b39c69f Netherlands (NL) | |
| 46d67ebe-006d-48c2-aa49-43bf61b98317 Poland (PL) | |
| 92684020-ce41-4128-bc03-779a109dcacf Norway (NO) | |
| 561c8bc7-a481-472b-91ee-89d64e0b99e0 Finland (FI) | |
| 32856ed0-d86e-4460-ac3f-7333a17b5003 Netherlands (NL) | |
| 63bda684-35c4-44be-bb90-ae9d7977eba7 Germany (DE) | |
| b1915684-c70f-44a8-81de-5906ba5418ab Denmark (DK) | |
| 9dc84237-145b-487a-9927-787ed09657f9 Germany (DE) | |
| 67d9cbf6-6362-431e-9ae0-5d4e0de6b081 Croatia (HR) | |
| d311c417-24da-44fe-b40d-42e2809af7ec Czech Republic (CZ) | |
| ccc90e55-acef-4dfb-a51f-b541cd3bf7cc Poland (PL) | |
| e7980283-fd9c-4a3f-931d-c8a03f9c9050 Netherlands (NL) | |
| 5a257c46-6a7c-4843-b109-04b9948cc475 Netherlands (NL) | |
| 2eb15806-5ced-496e-984e-b9bc79424b46 Estonia (EE) | |
| 8bd96530-fe60-4637-9933-37da0b89e684 Greece (GR) | |
| 6c4d505e-c43b-4171-b85e-93df4c8c2b15 Portugal (PT) | |
| f43f47c2-c1a6-4422-82ce-6364eb0b50c8 Bulgaria (BG) | |
| Ordering | |
| Order Code US and Canada | KXT4EPFPHR-4 |
| EAN | 8015644696306 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389099 |
| Dimensions | |
| Product Net Weight | 1.75 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 175 mm |
| Package Level 1 Height | 225 mm |
| Package Level 1 Depth / Length | 195 mm |
| Package Level 1 Gross Weight | 1.9 kg |
| Package Level 1 EAN | 8015644696306 |
| Additional Information | |
| Configuration Type | Loose or configurable |
| Number of Poles | 4 |
| Order Multiple | 1 piece |
| Product Main Type | Accessories for Tmax XT |
| Product Name | Accessory |
| Product Type | Fixed Part |
| Rated Frequency (f) | 50 / 60 Hz |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| 500 V DC | |
| Rated Uninterrupted Current (Iu) | 250 A |
| Standards | IEC60947-2 |
| Sub-type | XT4 |
| Suitable For | XT4 |
| Suitable for Product Class | SACE Tmax XT |
| Terminal Connection Type | Plug-In Circuit-Breakers |
| Rear flat Horizontal | |
| Version | P |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | Refer to the EU Declaration of the relative Circuit Breaker |
| Instructions and Manuals | 1SDH000722R0005 |
| Classifications | |
| ETIM 7 | EC002043 - Chassis part power circuit breaker |
| ETIM 8 | EC002043 - Chassis part power circuit breaker |
| ETIM 9 | EC002043 - Chassis part power circuit breaker |
| IDEA Granular Category Code (IGCC) | 5219 >> Switch part or accessory |
| Object Classification Code | Q |
| UNSPSC | 39122221 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370422 |
