ABB 1SDA068200R1 1SDA068200R1 ABB XT2 W FP 3p EF View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SDA068200R1 ABB XT2 W FP 3p EF

1SDA068200R1

068200

ABB

1 Pcs.

XT2 W FP 3p EF 3P TERM REMOVABLE BASE. EF W FP-XT2

Automation > Chassis part power circuit breaker
XT2

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A 1SDA068200R1 ABB XT2 W FP 3p EF functions as a three-pole fixed socket base designed to receive molded case circuit breakers, facilitating quick replacement and maintenance cycles in electrical control panels. This unit provides secure mechanical mounting and integrated electrical terminals.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
  • Toxic Substances Control Act - TSCA: 9AKK108467A8326
  • Environmental Information: 9AKK108467A6707
  • REACH Declaration: 9AKK108466A1425
  • RoHS Information: 9AKK108466A1424
  • RoHS Status: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
  • Order Code US and Canada: KXT2WFPEF-3
  • E-Number (Finland): 3640811
  • EAN: 8015644020965
  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85389099
  • Product Net Weight: 1.37 kg
  • Package Level 1 Units: box 1 piece
  • Package Level 1 Width: 175 mm
  • Package Level 1 Height: 225 mm
  • Package Level 1 Depth / Length: 195 mm

More info

▲
Circular Value
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
Toxic Substances Control Act - TSCA9AKK108467A8326
Environmental
Environmental Information9AKK108467A6707
REACH Declaration9AKK108466A1425
RoHS Information9AKK108466A1424
RoHS StatusFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Ordering
Order Code US and CanadaKXT2WFPEF-3
E-Number (Finland)3640811
EAN8015644020965
Minimum Order Quantity1 piece
Customs Tariff Number85389099
Dimensions
Product Net Weight1.37 kg
Container Information
Package Level 1 Unitsbox 1 piece
Package Level 1 Width175 mm
Package Level 1 Height225 mm
Package Level 1 Depth / Length195 mm
Package Level 1 Gross Weight1.506 kg
Package Level 1 EAN8015644020965
Additional Information
Configuration TypeLoose or configurable
Number of Poles3
Order Multiple1 piece
Product Main TypeAccessories for Tmax XT
Product NameAccessory
Product TypeFixed Part
Rated Frequency (f)50 / 60 Hz
Rated Impulse Withstand Voltage (Uimp)8 kV
Rated Insulation Voltage (Ui)1000 V
Rated Operational Voltage690 V AC
500 V DC
Rated Uninterrupted Current (Iu)160 A
StandardsIEC60947-2
UL489
Sub-typeXT2
Suitable ForXT2
Suitable for Product ClassSACE Tmax XT
Terminal Connection TypeWithdrawable Circuit-Breakers
Front Extended
VersionW
Certificates and Declarations
Data Sheet, Technical Information1SDC210100D0206
1SDC210099D0206
Declaration of Conformity - CERefer to the EU Declaration of the relative Circuit Breaker
Instructions and Manuals1SDH000721R0005
Classifications
ETIM 7EC002043 - Chassis part power circuit breaker
ETIM 8EC002043 - Chassis part power circuit breaker
ETIM 9EC002043 - Chassis part power circuit breaker
IDEA Granular Category Code (IGCC)5219 >> Switch part or accessory
Object Classification CodeQ
UNSPSC39122221
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
eClassV11.1 : 27370422

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
