View larger
Images are for illustrative purposes only. Please refer to data sheet for details
1SDA068185R1 ABB XT1 P FP 4p EF
1SDA068185R1
068185
ABB
1 Pcs.
XT1 P FP 4p EF
4P THERMAL PLUG-IN BASE. EF P FP-XT1
Automation > Chassis part power circuit breaker
XT1
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| ABB EcoSolutions | |
|---|---|
| Environmental Product Declaration - EPD | 9AKK108469A8952 |
| 9AKK108471A0810 | |
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| SCIP | 5b1b8cd0-8a91-4b2b-9dbf-e0a7f01949a9 Italy |
| Simplified SCIP | bd1d0fb8-826e-484e-bcc0-70a67dc013fd Belgium |
| 0131d033-7363-445d-8896-8e27c8dce2fc Hungary | |
| c56edb0f-a957-4785-a704-41cb0d131beb Spain | |
| 36c5b47b-813e-45d5-bf56-4138f5e6e3d6 France | |
| f63931e1-c714-426a-b3f2-08ca5a6c5a3f Denmark | |
| 366f5b2b-4896-4066-ac11-5629e43dbede Germany | |
| 95ed4f51-5a36-4631-be8a-7eaf7b777bcc Croatia | |
| 23cb0ee2-5f69-4166-928c-6a1667f20c84 Germany | |
| f94639a3-1c82-47ac-843e-f40332991d06 Sweden | |
| e3a86b3b-b0b2-435b-8f38-b1c9d7286cbb Germany | |
| 7e4a368b-4ad1-4cd7-b578-7a6fa5ebdf54 Czech Republic | |
| 72241d3a-ffa6-4221-8923-8296ef10c533 Germany | |
| eff835d7-2d7f-4577-a73a-219060ea45f2 Greece | |
| ad408da2-dfca-435b-a645-40f67dbe2474 France | |
| 6fef520b-0a41-4c96-9ea6-57c88cc44fdb Belgium | |
| a845c1ef-cfff-46ac-8a57-d1280c7e8cd7 Estonia | |
| ed48b57d-32d1-47ee-9b84-50aeec8cce0a Poland | |
| 334bd581-51d6-4a00-bdaa-87d9d56e8459 Finland | |
| 6c599692-b9d1-4d94-910f-a3d01449b14c Hungary | |
| ccd723ea-0a85-416c-b92f-21c667eda560 Norway | |
| 2f783fdc-80b4-4f81-b304-b7b3c7c0be91 Sweden | |
| e01b0b48-ea79-4ad2-a2f2-63de134973e4 Netherlands | |
| 39419dc3-0237-4f06-982e-cfd586600bc2 Germany | |
| 1727304d-fe34-45d3-8fc8-795031414eb9 Poland | |
| f04dfdc2-b747-4a14-b5f0-7ca656283cba Portugal | |
| fde4ad12-95f7-4ce2-b73a-6f868ecbc6bb Poland | |
| 5fd1f6de-6d4c-4614-b7de-1fd9bdfaf2ce Bulgaria | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| Order Code US and Canada | KXT1PFPEF-4 |
| E-Number (Finland) | 3640547 |
| E-Number (Norway) | 4381504 |
| EAN | 8015644020828 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389099 |
| Dimensions | |
| Product Net Weight | 0.89 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 120 mm |
| Package Level 1 Height | 155 mm |
| Package Level 1 Depth / Length | 190 mm |
| Package Level 1 Gross Weight | 0.99 kg |
| Package Level 1 EAN | 8015644020828 |
| Additional Information | |
| Product Main Type | Accessories for Tmax XT |
| Product Name | Accessory |
| Product Type | Fixed Part |
| Suitable For | XT1 |
| Suitable for Product Class | SACE Tmax XT |
| Version | P |
| Technical | |
| Configuration Type | Loose or configurable |
| Number of Poles | 4P |
| Order Multiple | 1 piece |
| Rated Frequency (f) | 50 / 60 Hz |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 800 V |
| Rated Operational Voltage | 690 V AC |
| 500 V DC | |
| Rated Uninterrupted Current (Iu) | 160 A |
| Standards | IEC60947-2 |
| UL489 | |
| Sub-type | XT1 |
| Terminal Connection Type | Plug-In Circuit-Breakers |
| Front Extended | |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | Refer to the EU Declaration of the relative Circuit Breaker |
| Instructions and Manuals | 1SDH000719R0005 |
| External Classifications and Standards | |
| ETIM 9 | EC002043 - Chassis part power circuit breaker |
| ETIM 10 | EC002043 - Chassis part power circuit breaker |
| IDEA Granular Category Code (IGCC) | 5219 >> Switch part or accessory |
| Object Classification Code | Q |
| UNSPSC | 39122221 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370422 |
