ABB 2CSG112210R4001 2CSG112210R4001 ABB VLM-1-400/72 Analogue voltmeter View larger
Images are for illustrative purposes only. Please refer to data sheet for details

2CSG112210R4001 ABB VLM-1-400/72 Analogue voltmeter

2CSG112210R4001

112210

ABB

1 Pcs.

VLM-1-400/72 Analogue voltmeter VLM-1-400/72 panel voltage

Automation > Voltmeter for installation
Measure, various ITSCE

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An analogue voltmeter such as the Abb 2CSG112210R4001 delivers continuous visual indication of electrical potential within industrial switchgear and control panels. These analogue measurement tools allow technicians to observe voltage fluctuations without complex digital interfaces. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Meter Type: Analogue
  • Mounting Type: Front-panel
  • Voltage Range: 400 V AC
  • Dimensions: 72 mm x 72 mm

More info

▲

VLM-1-400/72 is an 72x72mm front-panel analogue voltmeter for ac networks. Direct insertion.

Ordering

  • EAN:
    8012542544906
  • Minimum Order Quantity:
    1 piece
  • Customs Tariff Number:
    90303100

Dimensions

  • Product Net Width:
    0.053m
  • Product Net Height:
    0.072m
  • Product Net Depth:
    0.072m
  • Product Net Weight:
    0.200kg

Container Information

  • Package Level 1 Units:
    1 piece
  • Package Level 1 Width:
    0.12 m
  • Package Level 1 Height:
    0.08 m
  • Package Level 1 Length:
    0.08 m
  • Package Level 1 Gross Weight:
    0.3 kg
  • Package Level 1 EAN:
    8012542544906

Technical

  • Meter Type:
    Analogue
  • Mounting Type:
    Front-panel
  • Dimensions:
    72 mm x 72 mm
  • Voltage Range:
    400 V AC
  • Power Loss:
    at Rated Operating Conditions per Pole 1.5 W

Environmental

  • RoHS Status:
    Following EU Directive 2002/95/EC August 18, 2005 and amendment

Certificates and Declarations (Document Number)

Classifications

  • Object Classification Code:
    P
  • ETIM 4:
    EC001438 - Voltage monitoring relay
  • ETIM 5:
    EC001438 - Voltage monitoring relay
