ABB 1SDA063736R1 1SDA063736R1 ABB RATING PLUG EXTRACODIGO In1000A RC-T7/X1 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SDA063736R1 ABB RATING PLUG EXTRACODIGO In1000A RC-T7/X1

1SDA063736R1

063736

ABB

1 Pcs.

RATING PLUG EXTRACODIGO In1000A RC-T7/X1 RAT. Rc In1000PR332Rc-3T7-T7M-X1-T8 EXT

Automation > Accessories/spare parts for low-voltage switch technology
Molded case "Isomax-Tmax"

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

ABB 1SDA063736R1 is a rating plug designed to configure the continuous current rating (In1000A) of compatible electronic trip units on Tmax T7 and X1 circuit breakers. Rating plugs allow precise matching of circuit breaker protection characteristics to specific downstream cable and load requirements.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • REACH Declaration: 9AKK108466A1425
  • RoHS Declaration: 9AKK108466A1424
  • RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
  • Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
  • Toxic Substances Control Act - TSCA: 9AKK108467A8326
  • Environmental Information: 9AKK108467A6707
  • EAN: 8015644665425
  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85389099
  • Product Net Weight: 1 kg
  • Package Level 1 Units: 1 piece
  • Package Level 1 EAN: 8015644665425
  • Product Main Type: Accessories for Tmax T
  • Product Name: Accessory
  • Product Type: Accessory
  • Suitable For: T7, X1

More info

▲
ABB EcoSolutions
Material Compliance
REACH Declaration9AKK108466A1425
RoHS Declaration9AKK108466A1424
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
Toxic Substances Control Act - TSCA9AKK108467A8326
Environmental
Environmental Information9AKK108467A6707
Ordering
EAN8015644665425
Minimum Order Quantity1 piece
Customs Tariff Number85389099
Dimensions
Product Net Weight1 kg
Container Information
Package Level 1 Units1 piece
Package Level 1 EAN8015644665425
Additional Information
Product Main TypeAccessories for Tmax T
Product NameAccessory
Product TypeAccessory
Suitable ForT7, X1
Suitable for Product ClassSACE Emax
SACE Tmax T
Technical
Configuration TypeMounted only
Rated Current (In)1000 A
StandardsIEC
Certificates and Declarations
Data Sheet, Technical Information1SDC210015D0201
Declaration of Conformity - CERefer to the EU Declaration of the relative Circuit Breaker
Instructions and Manuals1SDC210015D0201
External Classifications and Standards
ETIM 9EC002498 - Accessories/spare parts for low-voltage switch technology
ETIM 10EC002498 - Accessories/spare parts for low-voltage switch technology
Object Classification CodeQ
UNSPSC39120000
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
eClassV11.1 : 27371390
