1SDA063460R1 ABB T4L 250 W FP 3p FC Cu 1000V AC
1SDA063460R1
063460
ABB
1 Pcs.
Automation > Chassis part power circuit breaker
T4
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The ABB T4L 250 W FP 3p FC Cu 1000V AC serves as a stationary mounting base that allows plug-in molded case circuit breakers to integrate into demanding alternating current electrical systems. Fixed parts of this nature provide secure mechanical support and stable terminal connections, enabling safe removal and replacement of switching units during maintenance cycles.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- REACH Declaration: 9AKK108466A1425
- RoHS Declaration: 9AKK108466A1424
- RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
- Toxic Substances Control Act - TSCA: 9AKK108467A8326
- Environmental Information: 9AKK108467A6707
- EAN: 8015644660840
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85389099
- Product Net Weight: 2.5 kg
- Package Level 1 Units: 1 piece
- Product Main Type: Accessories for Tmax T
- Product Name: Accessory
- Product Type: Fixed Part
- Version: W
- Current Type: AC
More info
▲| ABB EcoSolutions | |
|---|---|
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| EAN | 8015644660840 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389099 |
| Dimensions | |
| Product Net Weight | 2.5 kg |
| Container Information | |
| Package Level 1 Units | 1 piece |
| Additional Information | |
| Product Main Type | Accessories for Tmax T |
| Product Name | Accessory |
| Product Type | Fixed Part |
| Version | W |
| Technical | |
| Current Type | AC |
| Number of Poles | 3P |
| Rated Operational Voltage | 1000 V AC |
| Rated Uninterrupted Current (Iu) | 250 A |
| Short-Circuit Performance Level | L |
| Standards | IEC |
| Sub-type | T4 |
| Terminal Connection Type | Withdrawable Circuit-Breakers |
| Front for Copper Cables | |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210015D0208 |
| 1SDC210300D0201 | |
| Declaration of Conformity - CE | Refer to the EU Declaration of the relative Circuit Breaker |
| Instructions and Manuals | 1SDH000569R0001 |
| External Classifications and Standards | |
| ETIM 9 | EC002043 - Chassis part power circuit breaker |
| ETIM 10 | EC002043 - Chassis part power circuit breaker |
| Object Classification Code | Q |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370422 |
