2CDD281101R0032 ABB SD201/32 Switch Disconnector 1P, 32A
2CDD281101R0032
281101
ABB
1 Pcs.
Automation > Main switch for distribution board
E200
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An ABB SD201/32 Switch Disconnector 1P, 32A acts as a single-pole manual control switch designed for safe circuit interruption in modular electrical installations. Maintenance personnel use such devices to isolate individual branch lines and secure equipment during repairs.
Pricing, availability, and lead time are confirmed per enquiry through an RFQ.
- ABB EcoSolutions: Yes
- EcoSolutions Profile: 9AKK108470A9360
- Recyclability Rate of the Product acc. to EN45555: Design for Closing Resource Loops - Standard EN45555: 85 %
- ABB Site Meeting Group Waste To Landfill Target: No non-hazardous waste is sent to a landfill
- Extended Product Lifetime: Product Durability
- End Of Life Disassembling Instructions: 9AKK108469A8855
- Environmental Product Declaration - EPD: 9AKK108470A9091
- Contact Position Indication: ON / OFF
- Electrical Endurance: 10000 AC cycle
- Mechanical Endurance: 20000 cycle
- Number of Poles: 1P
- Tightening Torque: 2.8 N·m
- Utilization Category: Switching of motor loads or other highly inductive loads - frequent actuation (AC-23A)
- Actuator Type: Toggle
- Screw Terminal Type: Failsafe Bi-directional Cylinder-lift Terminal
- Switch Type: Off
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| EcoSolutions Profile | 9AKK108470A9360 |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 85 % |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill |
| Extended Product Lifetime | Product Durability |
| End Of Life Disassembling Instructions | 9AKK108469A8855 |
| Environmental Product Declaration - EPD | 9AKK108470A9091 |
| Technical | |
| Contact Position Indication | ON / OFF |
| Electrical Endurance | 10000 AC cycle |
| Mechanical Endurance | 20000 cycle |
| Number of Poles | 1P |
| Tightening Torque | 2.8 N·m |
| Utilization Category | Switching of motor loads or other highly inductive loads - frequent actuation (AC-23A) |
| Switching of resistive loads, including moderate overloads - frequent actuation (DC-21A) | |
| Actuator Type | Toggle |
| Screw Terminal Type | Failsafe Bi-directional Cylinder-lift Terminal |
| Switch Type | Off |
| Actuator Marking | I / O |
| Actuator Material | Insulation Group II, Red, Sealable |
| Recommended Screw Driver | Pozidriv 2 |
| Accessories Available | Yes |
| Cover Color | Grey |
| Connecting Capacity | Busbar 10/10 mm² |
| Flexible with Ferrule 0.75 ... 25 mm² | |
| Flexible 0.75 ... 25 mm² | |
| Rigid 0.75 ... 35 mm² | |
| Stranded 0.75 ... 35 mm² | |
| Terminal Type | Screw Terminals |
| Electrical | |
| Rated Voltage (Ur) | 253 V |
| 12 V Minimum | |
| Rated Operational Voltage | 253 V AC |
| 60 V DC | |
| Operational Voltage | Maximum 266 V AC |
| Maximum 63 V DC | |
| Minimum 12 V AC | |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| at 2000 m 5 kV | |
| at Sea Level 6.2 kV | |
| Input Voltage Type | AC/DC |
| Rated Current (In) | 32 A |
| Rated Conditional Short-Circuit Current (Inc) | 25 kA |
| Rated Frequency (f) | 50 / 60 Hz |
| DC | |
| Power Loss | at Rated Operating Conditions per Pole 1 W |
| Number of Contacts CO | 0 |
| Number of Contacts NC | 0 |
| Number of Contacts NO | 1 |
| Overvoltage Category | III |
| Design | |
| Housing Material | Insulation Group I, RAL 7035 |
| Material Compliance | |
| RoHS Declaration | 2CDK440034D2703 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date | 20210528 |
| REACH Declaration | 9AKK107492A1906 |
| REACH Information | False - does not contain substances > 0.1 mass percentage |
| REACH Date | 20251028 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer |
| Environmental | |
| Ambient Air Temperature | Operation -25 ... +55 °C |
| Storage -40 ... +70 °C | |
| Degree of Protection | IP20 |
| Enclosure with Cover IP40 | |
| Pollution Degree | 3 |
| Environmental Conditions | 28 cycles |
| with 55 °C / 90-96 % | |
| and 25 °C / 95-100 % | |
| Resistance to Vibrations | 20 Cycles with Load 0.8 In: 5g 5 ... 150 ... 5 Hz |
| Resistance to Shock acc. to IEC 60068-2-27 | 25g 2 shocks 13 ms |
| Environmental Information | 2CDK400618D0201 |
| Dimensions | |
| Width in Number of Modular Spacings | 1.0 |
| Product Net Width | 17.5 mm |
| Product Net Height | 88 mm |
| Product Net Depth / Length | 69 mm |
| Product Net Weight | 0.085 kg |
| Built-In Depth (t2) | 69 mm |
| Ordering | |
| Package Level 1 Units | carton 10 piece |
| Package Level 1 Gross Weight | 0.9 kg |
| E-Number (Finland) | 3601626 |
| E-Number (Norway) | 1429477 |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 2CDK440034D2703 |
| Installation | |
| Instructions and Manuals | 2CDS207104P0003 |
| Mounting Position | any |
| Popular Downloads | |
| Data Sheet, Technical Information | 2CDC441015D0201 |
| External Classifications and Standards | |
| ETIM 9 | EC001545 - Main switch for distribution board |
| ETIM 10 | EC001545 - Main switch for distribution board |
| UNSPSC | 39122233 |
| eClass | V11.0 : 27142301 |
| Object Classification Code | Q |
| Standards | IEC/EN 60947-3 |
| Certification Agency | IEC |
| EN | |
| Standardization Body | EN |
| IEC | |
