ABB 2CSS203997R0013 2CSS203997R0013 ABB S2C-CM2/3 Motor operating device View larger
Images are for illustrative purposes only. Please refer to data sheet for details

2CSS203997R0013 ABB S2C-CM2/3 Motor operating device

2CSS203997R0013

203997

ABB

1 Pcs.

S2C-CM2/3 - Motor operating device S2C-CM2/3 motor control for S200

Automation > Auxiliary device for distribution board devices
Accessories range compact (ITSCE)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The Abb 2CSS203997R0013 ABB S2C-CM2/3 Motor operating device operates as an electromechanical actuator designed to remotely control miniature circuit breakers. Such devices enable automated resetting and switching functions in distribution boards where remote management is required for safety or convenience. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Power Loss: at Rated Operating Conditions per Pole 1.5 W
  • Product Main Type: S2C-CM
  • Product Name: Motor operating device
  • Suitable For: S200
  • Suitable for Product Class: Miniature Circuit Breakers MCBs
  • Data Sheet, Technical Information: 2CSC400002D0209
  • Product Net Width: 0.036 m
  • Product Net Height: 0.089 m
  • Product Net Depth: 0.081 m
  • Product Net Weight: 0.163 kg
  • EAN: 8012542026358
  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85389099
  • Package Level 1 Units: 1 piece
  • Package Level 1 Width: 0.091 m
  • Package Level 1 Height: 0.09 m

More info

▲

The S2C-CM2/3 motor operating device has the function to allow the remote control (opening or closing) of the MCB it is associated to. It can assembled to 2 and 3 pole MCBs of S200 range.

Ordering

  • EAN:
    8012542026358
  • Minimum Order Quantity:
    1 piece
  • Customs Tariff Number:
    85389099

Dimensions

  • Product Net Width:
    0.036m
  • Product Net Height:
    0.089m
  • Product Net Depth:
    0.081m
  • Product Net Weight:
    0.163kg

Container Information

  • Package Level 1 Units:
    1 piece
  • Package Level 1 Width:
    0.091 m
  • Package Level 1 Height:
    0.09 m
  • Package Level 1 Length:
    0.092 m
  • Package Level 1 Gross Weight:
    0.236 kg
  • Package Level 1 EAN:
    8012542026358

Additional Information

  • Power Loss:
    at Rated Operating Conditions per Pole 1.5 W
  • Product Main Type:
    S2C-CM
  • Product Name:
    Motor operating device
  • Suitable For:
    S200
  • Suitable for Product Class:
    Miniature Circuit Breakers MCBs

Certificates and Declarations (Document Number)

Classifications

  • ETIM 4:
    EC000042 - Miniature circuit breaker (MCB)
  • ETIM 5:
    EC000042 - Miniature circuit breaker (MCB)
  • Object Classification Code:
    Q

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
