ABB 2CSS201997R0013 2CSS201997R0013 ABB S2C-CM1 Motor operating device View larger
Images are for illustrative purposes only. Please refer to data sheet for details

2CSS201997R0013 ABB S2C-CM1 Motor operating device

2CSS201997R0013

201997

ABB

1 Pcs.

S2C-CM1 - Motor operating device S2C-CM1 motor control for S200

Automation > Auxiliary device for distribution board devices
Accessories range compact (ITSCE)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed for integration with modular circuit protection, this Abb 2CSS201997R0013 ABB S2C-CM1 Motor operating device functions as a remote-control actuator for miniature circuit breakers. Industrial facilities deploy motor operators to remotely open, close, or reset protective breakers without requiring physical access to the panel. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Power Loss: at Rated Operating Conditions per Pole 1.5 W
  • Product Main Type: S2C-CM
  • Product Name: Motor operating device
  • Suitable For: S200
  • Suitable for Product Class: Miniature Circuit Breakers MCBs
  • Data Sheet, Technical Information: 2CSC400002D0209
  • Product Net Width: 0.036 m
  • Product Net Height: 0.089 m
  • Product Net Depth: 0.081 m
  • Product Net Weight: 0.168 kg
  • EAN: 8012542026259
  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85389099
  • Package Level 1 Units: 1 piece
  • Package Level 1 Width: 0.091 m
  • Package Level 1 Height: 0.09 m

More info

▲

The S2C-CM1 motor operating device has the function to allow the remote control (opening or closing) of the MCB it is associated to. It can assembled to 1 pole MCBs of S200 range.

Ordering

  • EAN:
    8012542026259
  • Minimum Order Quantity:
    1 piece
  • Customs Tariff Number:
    85389099

Dimensions

  • Product Net Width:
    0.036m
  • Product Net Height:
    0.089m
  • Product Net Depth:
    0.081m
  • Product Net Weight:
    0.168kg

Container Information

  • Package Level 1 Units:
    1 piece
  • Package Level 1 Width:
    0.091 m
  • Package Level 1 Height:
    0.09 m
  • Package Level 1 Length:
    0.092 m
  • Package Level 1 Gross Weight:
    0.24 kg
  • Package Level 1 EAN:
    8012542026259

Additional Information

  • Power Loss:
    at Rated Operating Conditions per Pole 1.5 W
  • Product Main Type:
    S2C-CM
  • Product Name:
    Motor operating device
  • Suitable For:
    S200
  • Suitable for Product Class:
    Miniature Circuit Breakers MCBs

Certificates and Declarations (Document Number)

Classifications

  • ETIM 4:
    EC000042 - Miniature circuit breaker (MCB)
  • ETIM 5:
    EC000042 - Miniature circuit breaker (MCB)
  • Object Classification Code:
    Q

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
