ABB 1SDA073772R1 1SDA073772R1 ABB RTC EKIP 24VDC E1.2 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SDA073772R1 ABB RTC EKIP 24VDC E1.2

1SDA073772R1

073772

ABB

1 Pcs.

RTC EKIP 24VDC E1.2 PRTN READY TO CLOSE Ekip 24V-E1.2 RTC EKIP 24VDC E1.2-XT7M

Automation > Auxiliary contact block
Accessories E1.2

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

1SDA073772R1 ABB RTC EKIP 24VDC E1.2 is a specialized electronic release accessory designed to provide ready-to-close signaling for air circuit breakers in automated electrical networks. Such units verify that protective trip units and operating mechanisms are properly energized and ready to accept a closing command.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • REACH Declaration: 9AKK108466A1425
  • RoHS Declaration: 9AKK108466A1424
  • RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
  • Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
  • Toxic Substances Control Act - TSCA: 9AKK108467A8326
  • Environmental Information: 9AKK108467A6707
  • Order Code US and Canada: ZE1RTCDE
  • EAN: 8015644777050
  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85389099
  • Product Net Width: 300 mm
  • Product Net Height: 50 mm
  • Product Net Depth / Length: 400 mm
  • Product Net Weight: 0.2 kg
  • Package Level 1 Units: box 1 piece
  • Package Level 1 Width: 300 mm

More info

▲
ABB EcoSolutions
Material Compliance
REACH Declaration9AKK108466A1425
RoHS Declaration9AKK108466A1424
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
Toxic Substances Control Act - TSCA9AKK108467A8326
Environmental
Environmental Information9AKK108467A6707
Ordering
Order Code US and CanadaZE1RTCDE
EAN8015644777050
Minimum Order Quantity1 piece
Customs Tariff Number85389099
Dimensions
Product Net Width300 mm
Product Net Height50 mm
Product Net Depth / Length400 mm
Product Net Weight0.2 kg
Container Information
Package Level 1 Unitsbox 1 piece
Package Level 1 Width300 mm
Package Level 1 Height50 mm
Package Level 1 Depth / Length400 mm
Package Level 1 Gross Weight0.2 kg
Package Level 1 EAN8015644777050
Additional Information
Product Main TypeAccessories for Emax 2, Accessories for Tmax XT
Product NameAccessory
Product TypeAccessory
Suitable ForXT7-XT7M, E1.2
Suitable for Product ClassSACE Tmax XT, SACE Emax 2
Technical
Configuration TypeLoose or configurable
Number of Auxiliary Contacts CO (SPDT)1
Order Multiple1 piece
StandardsIEC
Certificates and Declarations
Data Sheet, Technical Information1SDC200023D0209
1SDC210100D0204
Declaration of Conformity - CE9AKK106713A5546
Instructions and Manuals1SDH000999R0614
External Classifications and Standards
ETIM 9EC000041 - Auxiliary contact block
ETIM 10EC000041 - Auxiliary contact block
IDEA Granular Category Code (IGCC)4743 >> Auxiliary contact block
Object Classification CodeQ
UNSPSC39121522
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
eClassV11.1 : 27371302

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
