ABB 1SFA619102R1213 1SFA619102R1213 ABB PUSHBUTTON CP3-12Y-10 110-130V AC/DC View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SFA619102R1213 ABB PUSHBUTTON CP3-12Y-10 110-130V AC/DC

1SFA619102R1213

10110

ABB

1 Pcs.

PUSHBUTTON#CP3-12Y-10#110-130V AC/DC P.EXT. COMP. LUM. LOVE. MOMEN. 1NA 130V AC/

Automation > Push button, complete
elements PDA

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Configured as a pushbutton, the ABB 1SFA619102R1213 component allows operators to manually issue control commands to industrial automation systems. Illuminated pushbuttons are frequently installed on control desks and panels to provide clear visual status feedback alongside tactile switching capabilities.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Ambient Air Temperature: Operation -25 … +70 °C
  • RoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendment
  • Actuator Type: Extended
  • Additional Information: Ill. PB
  • Bezel Material: Black plastic
  • Block: 1NO
  • Color: Yellow
  • Degree of Protection: acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20
  • Function: Momentary
  • Illumination: Illuminated
  • Lamp Type: LED 110-130V AC/DC
  • Lens Color: Yellow
  • Lower Button Color: Yellow
  • Mechanical Durability: 0.5 million
  • Number of Auxiliary Contacts NO: 1
  • Order Multiple: 1 piece

More info

▲

Compact Pushbutton - Momentary - Extended - Yellow - Illuminated - Black plastic - 1NO

Ordering

  • EAN:
    7320500381618
  • Minimum Order Quantity:
    10 piece
  • Customs Tariff Number:
    85369001

Dimensions

  • Product Net Width:
    0.030m
  • Product Net Height:
    0.030m
  • Product Net Depth:
    0.055m
  • Product Net Weight:
    0.018kg

Environmental

  • Ambient Air Temperature:
    Operation -25 … +70 °C
  • RoHS Status:
    Following EU Directive 2002/95/EC August 18, 2005 and amendment

Additional Information

  • Actuator Type:
    Extended
  • Additional Information:
    Ill. PB
  • Bezel Material:
    Black plastic
  • Block:
    1NO
  • Color:
    Yellow
  • Degree of Protection:
    acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20
  • Function:
    Momentary
  • Illumination:
    Illuminated
  • Lamp Type:
    LED 110-130V AC/DC
  • Lens Color:
    Yellow
  • Lower Button Color:
    Yellow
  • Mechanical Durability:
    0.5 million
  • Number of Auxiliary Contacts NO:
    1
  • Order Multiple:
    1 piece
  • Product Main Type:
    CP3
  • Product Name:
    Pushbutton
  • Product Range:
    Compact
  • Product Type:
    CP
  • Rated Frequency (f):
    50 / 60 Hz
  • Rated Operational Current AC-15 (Ie):
    (240 V) 1 A
    (120 V) 1.5 A
  • Rated Operational Current DC-13 (Ie):
    (125 V) 0.2 A
    (24 V) 0.3 A
  • Rated Operational Voltage:
    110…130 V AC/DC
  • RoHS Date:
    0626 5

Certificates and Declarations (Document Number)

Classifications

  • E-nummer:
    3717267
  • ETIM 4:
    EC002024 - Accessories for control circuit devices
  • ETIM 5:
    EC002024 - Accessories for control circuit devices
  • Object Classification Code:
    S
