ABB 1SCA022772R7910 1SCA022772R7910 ABB OTVY250EK Handle View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SCA022772R7910 ABB OTVY250EK Handle

1SCA022772R7910

022772

ABB

1 Pcs.

OTVY250EK Handle Direct control OTVY250EK OTVY250EK HANDLE+COVER

Automation > Handle for power circuit breaker
Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

ABB OTVY250EK Handle acts as a manual actuator component engineered for industrial switch disconnectors, allowing operators to safely open and close high-amperage circuits. These handles attach to operating shafts to ensure secure mechanical control from the exterior of electrical enclosures. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
  • REACH Declaration: 1SCC011021D0201
  • RoHS Declaration: 1SCC011020D0201
  • RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
  • Data Sheet, Technical Information: 1SCC301020C0201
  • Instructions and Manuals: 1SCC301031M0008
  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85389099
  • Country or Territory of Origin: Finland
  • Product Net Width: 50 mm
  • Product Net Height: 100 mm
  • Product Net Depth / Length: 50 mm
  • Product Net Weight: 0.075 kg
  • Package Level 1 Units: 1 piece
  • Package Level 1 Width: 50 mm
  • Package Level 1 Depth / Length: 100 mm

More info

▲
Material Compliance
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
REACH Declaration1SCC011021D0201
RoHS Declaration1SCC011020D0201
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Popular Downloads
Data Sheet, Technical Information1SCC301020C0201
Instructions and Manuals1SCC301031M0008
Ordering
Minimum Order Quantity1 piece
Customs Tariff Number85389099
Country or Territory of OriginFinland
Dimensions
Product Net Width50 mm
Product Net Height100 mm
Product Net Depth / Length50 mm
Product Net Weight0.075 kg
Container Information
Package Level 1 Units1 piece
Package Level 1 Width50 mm
Package Level 1 Depth / Length100 mm
Package Level 1 Height50 mm
Package Level 1 Gross Weight0.1 kg
Package Level 1 EAN6417019253862
Technical
Special FunctionsEK
Certificates and Declarations
External Classifications and Standards
Object Classification CodeN/A
ETIM 9EC000229 - Handle for power circuit breaker
ETIM 10EC000229 - Handle for power circuit breaker
UNSPSC39122230
eClassV11.1 : 27370414
WEEE CategoryProduct Not in WEEE Scope
E-Number (Finland)3602137

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
