OT630KLAA6BZ 1SCA022834R1420 ABB OT630KLAA6BZ Enclosed switch
OT630KLAA6BZ
1SCA022834R1420
ABB
1 Pcs.
Connectors > Switch disconnector
Box
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Abb part number OT630KLAA6BZ is an Abb enclosed switch engineered to provide secure power isolation in demanding industrial environments. Housed units protect internal switching mechanisms from dust, moisture, and accidental contact while allowing convenient exterior operation. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- RoHS Declaration: 1SCC340049D0202
- RoHS Information: Following EU Directive 2011/65/EU
- Data Sheet, Technical Information: 1SCC340015C0201
- Instructions and Manuals: 1SCC340005M0007
- Mechanical Drawings: OTKM108023PO.stp
- Degree of Protection: acc. to IEC 60529 IP65
- Pollution Degree: 3
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85363090
- Replacement Product ID (NEW): OT630KLUU6BZ
- Country or Territory of Origin: Finland
- Product Net Width: 800 mm
- Product Net Height: 1000 mm
- Product Net Depth / Length: 230 mm
- Product Net Weight: 39.8 kg
- Package Level 1 Units: box 1 piece
More info
▲| Material Compliance | |
|---|---|
| RoHS Declaration | 1SCC340049D0202 |
| RoHS Information | Following EU Directive 2011/65/EU |
| Popular Downloads | |
| Data Sheet, Technical Information | 1SCC340015C0201 |
| Instructions and Manuals | 1SCC340005M0007 |
| Mechanical Drawings | OTKM108023PO.stp |
| Environmental | |
| Degree of Protection | acc. to IEC 60529 IP65 |
| Pollution Degree | 3 |
| Ordering | |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85363090 |
| Replacement Product ID (NEW) | OT630KLUU6BZ |
| Country or Territory of Origin | Finland |
| Dimensions | |
| Product Net Width | 800 mm |
| Product Net Height | 1000 mm |
| Product Net Depth / Length | 230 mm |
| Product Net Weight | 39.8 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 815 mm |
| Package Level 1 Depth / Length | 1310 mm |
| Package Level 1 Height | 425 mm |
| Package Level 1 Gross Weight | 46 kg |
| Package Level 1 EAN | 6417019289502 |
| Technical | |
| Cable Entry Position | Up/Down |
| Cable Outlets Per Side | Open / Open |
| Connecting Capacity Main Circuit | Hole Diameter 12 mm |
| Screw Clamp / PE Terminal 8pcs, 25…120 mm² | |
| Conventional Thermal Current (Ithe) | Fully Enclosed 570 A |
| Degree of Protection | acc. to IEC 60529 IP65 |
| Enclosure Material | Steel sheet |
| Handle Color | Black |
| Handle Type | Pistol handle |
| Maximum Mounted Auxiliary Contacts | 4 NO, 2 NC |
| Mounted Auxiliary Contacts | 0 NO, 0 NC |
| Number of Poles | 6P |
| Pollution Degree | 3 |
| Power Loss | at Rated Operating Conditions per Pole 25 W |
| Rated Conditional Short-Circuit Current (Inc) | 90 kA |
| Rated Impulse Withstand Voltage (Uimp) | 20 kV |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 1000 V |
| Rated Operational Current AC-22A (Ie) | (380 ... 415 V) 570 A |
| (690 V) 570 A | |
| Rated Operational Current AC-23A (Ie) | (380 ... 415 V) 570 A |
| (690 V) 570 A | |
| Rated Operational Power AC-23A (Pe) | (380 ... 415 V) 315 kW |
| (500 V) 400 kW | |
| (690 V) 560 kW | |
| Rated Operational Voltage | Main Circuit 1000 V |
| Rated Short-Circuit Making Capacity (Icm) | (1000 V AC) 80 kA |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 20 kA |
| Standards | IEC 60947-1, -3 |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 1SCC340029D2704 |
| External Classifications and Standards | |
| Object Classification Code | Q |
| ETIM 10 | EC000216 - Switch disconnector (AC) |
| WEEE Category | 4. Large Equipment (Any External Dimension More Than 50 cm) |
