ABB 1SCA104834R1001 1SCA104834R1001 ABB OT16F6 switch-disconnector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SCA104834R1001 ABB OT16F6 switch-disconnector

1SCA104834R1001

104834

ABB

1 Pcs.

OT16F6 switch-disconnector OT16F6 Disconnect Switch OT16F6 SWITCH-DISCONNECTOR

Connectors > Switch disconnector
OT

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An ABB OT16F6 switch-disconnector provides compact manual load breaking and reliable circuit separation for control gear and electrical enclosures. Technicians use these multi-pole devices to route and isolate control signals and auxiliary power lines.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
  • Environmental Information: 1SCC301262D0201
  • Environmental Product Declaration - EPD: 1SCC301278D0201
  • REACH Declaration: 1SCC011021D0201
  • RoHS Information: 1SCC011020D0201
  • Toxic Substances Control Act - TSCA: 1SCC011025D0201
  • Environmental Product Declaration - EPD: 1SCC301278D0201
  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85365080
  • Country of Origin: Finland (FI)
  • Data Sheet, Technical Information: 1SCC301020C0201
  • Instructions and Manuals: 1SCC301055M0003
  • Mechanical Drawings: 1SCC301442F0001
  • Environmental Product Declaration - EPD: 1SCC301278D0201
  • Product Net Width: 70 mm
  • Product Net Height: 68 mm

More info

▲
Circular Value
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
Environmental Information1SCC301262D0201
Environmental Product Declaration - EPD1SCC301278D0201
REACH Declaration1SCC011021D0201
RoHS Information1SCC011020D0201
Toxic Substances Control Act - TSCA1SCC011025D0201
Eco Transparency
Environmental Product Declaration - EPD1SCC301278D0201
Ordering
Minimum Order Quantity1 piece
Customs Tariff Number85365080
Country of OriginFinland (FI)
Popular Downloads
Data Sheet, Technical Information1SCC301020C0201
Instructions and Manuals1SCC301055M0003
Mechanical Drawings1SCC301442F0001
1SCC301441F0001
OT16-40F6.igs
Environmental Product Declaration - EPD1SCC301278D0201
Dimensions
Product Net Width70 mm
Product Net Height68 mm
Product Net Depth / Length68 mm
Product Net Weight0.21 kg
Technical
Rated Operational Current AC-21A (Ie)(380 ... 415 V) 16 A
(500 V) 16 A
(690 V) 16 A
Rated Operational Current AC-22A (Ie)(380 ... 415 V) 16 A
(500 V) 16 A
(690 V) 16 A
Rated Operational Current AC-23A (Ie)(380 ... 415 V) 16 A
(500 V) 16 A
(690 V) 10 A
Rated Operational Power AC-23A (Pe)(220 ... 240 V) 3 kW
(400 ... 415 V) 7.5 kW
(500 V) 7.5 kW
(690 V) 7.5 kW
Conventional Free-air Thermal Current (Ith)Θ = 40 °C 25 A
Conventional Thermal Current (Ithe)Fully Enclosed 25 A
Rated Impulse Withstand Voltage (Uimp)8 kV
Rated Insulation Voltage (Ui)acc. to IEC/EN 60664-1 750 V
Rated Operational VoltageMain Circuit 750 V
Rated Short-Circuit Making Capacity (Icm)(690 V) 0.71 kA
Rated Short-time Withstand Current Low Voltage (Icw)for 1 s 0.5 kA
Rated Conditional Short-Circuit Current (Inc)(40 A fuse, ≤415V) 50 kA
(25 A fuse, 690 V) 50 kA
Power Lossat Rated Operating Conditions per Pole 0.3 W
Pollution Degree3
Handle TypeKnob
Handle and shaft not included
Switches Operating MechanismMechanism on Top of the Switch
Distance Between PhasesStandard
Position of Line TerminalsTop In - Bottom Out
Bottom In - Top Out
Operating ModeFront operated
StandardsIEC 60947-3 / UL 508 / CSA C22.2 No. 14
Special FunctionsNo
Mounting TypeBase mounting
Number of Poles6
Cable Cross-SectionCu 0.75 ... 10 mm²
Degree of ProtectionFront IP20
Terminal TypeScrew Terminals
Tightening Torqueacc. IEC 60947-1 0.8 N·m
Mechanical Durability20000
Lock TypeNo
Technical UL/CSA
Maximum Operating Voltage UL/CSA600 V
Ampere Rating20 A
Horsepower Rating UL/CSA(110 ... 120 V AC) Single Phase 1 Hp
(240 V AC) Single Phase 2 Hp
(440 ... 480 V AC) Single Phase 5 Hp
(550 ... 600 V AC) Single Phase 7.5 Hp
(220 ... 240 V AC) Three Phase 5 Hp
(440 ... 480 V AC) Three Phase 10 Hp
(550 ... 600 V AC) Three Phase 10 Hp
Tightening Torqueacc. IEC 60947-1 0.8 N·m
Tightening Torque UL/CSA7 in·lb
Environmental
RoHS StatusFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Environmental Information1SCC301262D0201
Toxic Substances Control Act - TSCA1SCC011025D0201
Certificates and Declarations
A2L Certificate – IEC1SCC301335D0201
ATEX CertificateNo certification needed
Declaration of Conformity - CE1SCC301166D2703
REACH Declaration1SCC011021D0201
UL CertificatecULus certificate OT16-80
VDE CertificateNo certification needed
Container Information
Package Level 1 Unitsbox 1 piece
Package Level 1 Width80 mm
Package Level 1 Depth / Length112 mm
Package Level 1 Height80 mm
Package Level 1 Gross Weight0.25 kg
Package Level 1 EAN6417019389783
Classifications
Object Classification CodeQ
ETIM 7EC000216 - Switch disconnector
ETIM 8EC000216 - Switch disconnector
ETIM 9EC000216 - Switch disconnector (low voltage)
UNSPSC39122233
IDEA Granular Category Code (IGCC)5290 >> Disconnect switch
eClassV11.1 : 27371403
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
E-Number (Finland)3601424
E-Number (Sweden)3172087

Product Datasheet
