MCBH-101 1SFA611605R1201 ABB MCBH-101 Contact block
MCBH-101
1SFA611605R1201
ABB
1 Pcs.
Automation > Lamp holder block for control circuit devices
elements PDA
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Abb MCBH-101 contact block mounts behind operator interface devices to open or close auxiliary electrical circuits when a pushbutton or switch is actuated. Such components serve as the foundational interface between mechanical control actions and industrial machine logic. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Minimum Order Quantity: 10 piece
- Customs Tariff Number: 8536901000
- Data Sheet, Technical Information: 1SFC151003C0201
- Instructions and Manuals: 1SFC151003C0201
- Product Net Width: 0.03 m
- Product Net Height: 0.048 m
- Product Net Depth / Length: 0.036 m
- Product Net Weight: 0.033 kg
- Illumination: Non-illuminated
- Lamp Type: Socket for max 230V AC / DC filament bulb or LED
- Function: With 3-position holder
- Mounting Type: Front mounting
- Number of Auxiliary Contacts NO: 1
- Rated Insulation Voltage (U i ): 690 V
- Rated Impulse Withstand Voltage (U imp ): 6 kV
- Rated Frequency (f): Supply Circuit 50 / 60 Hz
More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 10 piece |
| Customs Tariff Number | 8536901000 |
| Popular Downloads | |
| Data Sheet, Technical Information | 1SFC151003C0201 |
| Instructions and Manuals | 1SFC151003C0201 |
| Dimensions | |
| Product Net Width | 0.03 m |
| Product Net Height | 0.048 m |
| Product Net Depth / Length | 0.036 m |
| Product Net Weight | 0.033 kg |
| Technical | |
| Illumination | Non-illuminated |
| Lamp Type | Socket for max 230V AC / DC filament bulb or LED |
| Function | With 3-position holder |
| Mounting Type | Front mounting |
| Number of Auxiliary Contacts NO | 1 |
| Rated Insulation Voltage (Ui) | 690 V |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Frequency (f) | Supply Circuit 50 / 60 Hz |
| Rated Operational Voltage | 24 ... 230 V AC/DC |
| Rated Operational Current DC-13 (Ie) | (24 V) 5 A |
| (125 V) 1.1 A | |
| Rated Operational Current AC-15 (Ie) | (24 / 127 V) 8 A |
| (220 / 240 V) 6 A | |
| Mechanical Durability | 10 million |
| Connection Type | Screw Clamp |
| Suitable For | MP1 |
| MP2 | |
| MP3 | |
| MP4 | |
| MPD1 | |
| MPD2 | |
| MPD3 | |
| MPD4 | |
| MPD5 | |
| MPD11 | |
| MPD12 | |
| MPD13 | |
| MPD14 | |
| MPD15 | |
| MPD16 | |
| MPM1 | |
| MPM2 | |
| KP6 | |
| MPET3 | |
| MPEP3 | |
| MPEK3 | |
| MPET4 | |
| MPEP4 | |
| MPEK4 | |
| MPMT3 | |
| MPMT4 | |
| MPMP3 | |
| MPMP4 | |
| M2SS1 | |
| M2SS2 | |
| M2SS3 | |
| M2SS4 | |
| M2SS5 | |
| M2SS6 | |
| M3SS1 | |
| M3SS2 | |
| M3SS3 | |
| M3SS4 | |
| M3SS5 | |
| M3SS6 | |
| M3SS7 | |
| M3SS8 | |
| M3SSC1 | |
| M3SSC2 | |
| M3SSC3 | |
| M3SSC4 | |
| M3SSC5 | |
| M3SSC6 | |
| M3SSC7 | |
| M3SSC8 | |
| M2SSK1 | |
| M2SSK2 | |
| M2SSK3 | |
| M3SSK1 | |
| M3SSK2 | |
| M3SSK3 | |
| MTS1 | |
| MTS2 | |
| MTS3 | |
| MJS1 | |
| MJS2 | |
| MJS5 | |
| MJS6 | |
| MJS7 | |
| MJS8 | |
| MJS11 | |
| MJS12 | |
| Environmental | |
| Degree of Protection | Terminals IP20 |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| RoHS Declaration | 1SFC151011D0203 |
| RoHS Information | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Certificates and Declarations | |
| CQC Certificate | CQC2005010304154103 |
| Declaration of Conformity - CCC | 2020980305001528 |
| Declaration of Conformity - CE | 1SFA1-83 |
| Container Information | |
| Package Level 1 Units | 1 piece |
| Package Level 1 Width | 0.11 m |
| Package Level 1 Depth / Length | 0.15 m |
| Package Level 1 Height | 0.03 m |
| Package Level 1 Gross Weight | 0.033 kg |
| Package Level 1 EAN | 7320500307571 |
| External Classifications and Standards | |
| Object Classification Code | S |
| ETIM 6 | EC000041 - Auxiliary contact block |
| ETIM 7 | EC000204 - Lamp holder block for control circuit devices |
| ETIM 8 | EC000204 - Lamp holder block for control circuit devices |
| eClass | V11.0 : 27371302 |
| UNSPSC | 39121500 |
| E-Number (Norway) | 4372836 |
| E-Number (Sweden) | 3714041 |
