ABB 1SBV013841R1211 1SBV013841R1211 ABB LS33M41B11 Limit Switch View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SBV013841R1211 ABB LS33M41B11 Limit Switch

1SBV013841R1211

013841

ABB

1 Pcs.

LS33M41B11 Limit Switch End.Carr.PAL.C/RO. PLA. DIA.18(22 P/LS4X)

Automation > End switch
Limit FRCTLP

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

ABB LS33M41B11 is a limit switch equipped with a plastic roller lever, engineered to control and monitor mechanical motion across automated production lines. Industrial limit switches are standard components used to detect end-of-travel positions and route safety interlock signals. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85364900
  • Data Sheet, Technical Information: 1SBC141160C0201
  • Instructions and Manuals: 1SBC141160C0201
  • Product Net Width: 30 mm
  • Product Net Height: 108 mm
  • Product Net Depth / Length: 44 mm
  • Product Net Weight: 0.178 kg
  • Action Type of the Contact Element (acc. to IEC 60947-5-1): Snap Action Simultaneous
  • Actuator Type: plastic roller lever (Ø18 mm)
  • B10d Value: Operations 30 Millions
  • Conventional Free-air Thermal Current (I th ): acc. to IEC 60947-5-1, Θ = 40 °C 10 A
  • Degree of Protection: acc. to IEC 60529 IP66
  • Housing Material: Metal
  • Maximum Electrical Switching Frequency: (AC-15) 3600 cycles per hour
  • Maximum Mounted Auxiliary Contacts: 1 NO, 1 NC

More info

▲
Ordering
Minimum Order Quantity1 piece
Customs Tariff Number85364900
Popular Downloads
Data Sheet, Technical Information1SBC141160C0201
Instructions and Manuals1SBC141160C0201
Dimensions
Product Net Width30 mm
Product Net Height108 mm
Product Net Depth / Length44 mm
Product Net Weight0.178 kg
Technical
Action Type of the Contact Element (acc. to IEC 60947-5-1)Snap Action Simultaneous
Actuator Typeplastic roller lever (Ø18 mm)
B10d ValueOperations 30 Millions
Conventional Free-air Thermal Current (Ith)acc. to IEC 60947-5-1, Θ = 40 °C 10 A
Degree of Protectionacc. to IEC 60529 IP66
Housing MaterialMetal
Maximum Electrical Switching Frequency(AC-15) 3600 cycles per hour
(DC-13) 3600 cycles per hour
Maximum Mounted Auxiliary Contacts1 NO, 1 NC
Mechanical Durability15 million
Mounting Type30 mm (EN 50047)
Number and Type of Bottom Cable Glands1 x M20x1.5 - Bottom
Pilot Duty UL/CSAA600
Q600
Rated Impulse Withstand Voltage (Uimp)6 kV
Rated Operational Current AC-15 (Ie)(230 V AC) 3.1 A
(400 V) NC 4
(24 V) 10 A
(130 V) 5.5 A
(240 V) 3 A
Rated Insulation Voltage (Ui)acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 500 V
acc. to UL/CSA 600 V
Rated Operational Current DC-13 (Ie)(24 V) 6 A
(110 V) 0.6 A
(125 V) 0.55 A
(250 V) 0.4 A
Short-Circuit Protective DevicesgG Type Fuses 10 A
Environmental
Ambient Air TemperatureOperation -25 ... +70 °C
Storage -30 ... +80 °C
Material Compliance
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
REACH Declaration1SBD251109E1001
RoHS Declaration1SBD251110E1000
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA2CMT2023-006537
WEEE B2C / B2BBusiness To Business
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
Certificates and Declarations
CQC CertificateCQC2004010305127663
cUL Certificate9AKK107991A7379
Declaration of Conformity - CCC2020980305001785
Declaration of Conformity - CE1SBD250883U1000
Declaration of Conformity - UKCA1SBD250886U1000
Container Information
Package Level 1 Unitsbox 1 piece
Package Level 1 Width54 mm
Package Level 1 Depth / Length32 mm
Package Level 1 Height118 mm
Package Level 1 Gross Weight0.192 kg
Package Level 1 EAN3471522622860
External Classifications and Standards
Object Classification CodeB
ETIM 6EC000030 - End switch
ETIM 7EC000030 - End switch
ETIM 8EC000030 - End switch
eClassV11.0 : 27272601
UNSPSC39121500
