ABB 1SBV013812R1211 1SBV013812R1211 ABB LS33M12B11 Limit Switch View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SBV013812R1211 ABB LS33M12B11 Limit Switch

1SBV013812R1211

013812

ABB

1 Pcs.

LS33M12B11 Limit Switch Fin.Carr.CAB.ACTUAD.PULLEY STEEL

Automation > End switch
Limit FRCTLP

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An ABB LS33M12B11 Limit Switch functions as a rugged contact sensor deployed across factory environments to register the mechanical travel limits of automated actuators. Facilities engineering teams incorporate these heavy-duty components into material handling equipment and assembly cells to ensure precise positioning feedback. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85364900
  • Data Sheet, Technical Information: 1SBC141160C0201
  • Instructions and Manuals: 1SBC141160C0201
  • Product Net Width: 30 mm
  • Product Net Height: 85 mm
  • Product Net Depth / Length: 33 mm
  • Product Net Weight: 0.18 kg
  • Action Type of the Contact Element (acc. to IEC 60947-5-1): Snap Action Simultaneous
  • Actuator Type: steel roller plunger
  • B10d Value: Operations 30 Millions
  • Conventional Free-air Thermal Current (I th ): acc. to IEC 60947-5-1, Θ = 40 °C 10 A
  • Degree of Protection: acc. to IEC 60529 IP66
  • Housing Material: Metal
  • Maximum Electrical Switching Frequency: (AC-15) 3600 cycles per hour
  • Maximum Mounted Auxiliary Contacts: 1 NO, 1 NC

More info

▲
Ordering
Minimum Order Quantity1 piece
Customs Tariff Number85364900
Popular Downloads
Data Sheet, Technical Information1SBC141160C0201
Instructions and Manuals1SBC141160C0201
Dimensions
Product Net Width30 mm
Product Net Height85 mm
Product Net Depth / Length33 mm
Product Net Weight0.18 kg
Technical
Action Type of the Contact Element (acc. to IEC 60947-5-1)Snap Action Simultaneous
Actuator Typesteel roller plunger
B10d ValueOperations 30 Millions
Conventional Free-air Thermal Current (Ith)acc. to IEC 60947-5-1, Θ = 40 °C 10 A
Degree of Protectionacc. to IEC 60529 IP66
Housing MaterialMetal
Maximum Electrical Switching Frequency(AC-15) 3600 cycles per hour
(DC-13) 3600 cycles per hour
Maximum Mounted Auxiliary Contacts1 NO, 1 NC
Mechanical Durability>5 million
Mounting Type30 mm (EN 50047)
Number and Type of Bottom Cable Glands1 x M20x1.5 - Bottom
Pilot Duty UL/CSAA600
Q600
Rated Impulse Withstand Voltage (Uimp)6 kV
Rated Operational Current AC-15 (Ie)(230 V AC) 3.1 A
(400 V) NC 4
(24 V) 10 A
(130 V) 5.5 A
(240 V) 3 A
Rated Insulation Voltage (Ui)acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 500 V
acc. to UL/CSA 600 V
Rated Operational Current DC-13 (Ie)(24 V) 6 A
(110 V) 0.6 A
(125 V) 0.55 A
(250 V) 0.4 A
Short-Circuit Protective DevicesgG Type Fuses 10 A
Environmental
Ambient Air TemperatureOperation -25 ... +70 °C
Storage -30 ... +80 °C
Material Compliance
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
REACH Declaration1SBD251109E1001
RoHS Declaration1SBD251110E1000
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA2CMT2023-006537
WEEE B2C / B2BBusiness To Business
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
Certificates and Declarations
CQC CertificateCQC2004010305127663
cUL Certificate9AKK107991A7379
Declaration of Conformity - CCC2020980305001785
Declaration of Conformity - CE1SBD250883U1000
Declaration of Conformity - UKCA1SBD250886U1000
Container Information
Package Level 1 Unitsbox 1 piece
Package Level 1 Width32 mm
Package Level 1 Depth / Length35 mm
Package Level 1 Height95 mm
Package Level 1 Gross Weight0.19 kg
Package Level 1 EAN3471522622501
External Classifications and Standards
Object Classification CodeB
ETIM 6EC000030 - End switch
ETIM 7EC000030 - End switch
ETIM 8EC000030 - End switch
eClassV11.0 : 27272601
UNSPSC39121500
