LS21P12B11-P01 1SBV016012R3201 ABB LS21P12B11-P01 Limit Switch
LS21P12B11-P01
1SBV016012R3201
ABB
10 Pcs.
Automation > Position switch modular
Limit FRCTLP
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Monitor moving parts and structural components with the Abb LS21P12B11-P01 limit switch, designed to interrupt electrical control circuits upon reaching designated mechanical thresholds. Limit switches are essential components for automated positioning and safety feedback.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Minimum Order Quantity: 10 piece
- Customs Tariff Number: 85364900
- Replacement Product ID (NEW): 1SBV016012R3801
- Data Sheet, Technical Information: 1SBC141157C0202
- Instructions and Manuals: 1SBC141157C0202
- Product Net Width: 30 mm
- Product Net Height: 70 mm
- Product Net Depth / Length: 16 mm
- Product Net Weight: 0.127 kg
- B10d Value: Operations 20 Millions
- Conventional Free-air Thermal Current (I th ): acc. to IEC 60947-5-1, Θ = 40 °C 10 A
- Degree of Protection: acc. to IEC 60529 IP67
- Maximum Electrical Switching Frequency: (AC-15) 3600 cycles per hour
- Mechanical Durability: 30 million
- Rated Impulse Withstand Voltage (U imp ): 4 kV
- Rated Operational Current AC-15 (I e ): (24 V) 10 A
More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 10 piece |
| Customs Tariff Number | 85364900 |
| Replacement Product ID (NEW) | 1SBV016012R3801 |
| Popular Downloads | |
| Data Sheet, Technical Information | 1SBC141157C0202 |
| Instructions and Manuals | 1SBC141157C0202 |
| Dimensions | |
| Product Net Width | 30 mm |
| Product Net Height | 70 mm |
| Product Net Depth / Length | 16 mm |
| Product Net Weight | 0.127 kg |
| Technical | |
| B10d Value | Operations 20 Millions |
| Conventional Free-air Thermal Current (Ith) | acc. to IEC 60947-5-1, Θ = 40 °C 10 A |
| Degree of Protection | acc. to IEC 60529 IP67 |
| Maximum Electrical Switching Frequency | (AC-15) 3600 cycles per hour |
| (DC-13) 3600 cycles per hour | |
| Mechanical Durability | 30 million |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| Rated Operational Current AC-15 (Ie) | (24 V) 10 A |
| (130 V) 5.5 A | |
| (240 V) 3 A | |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 400 V |
| Rated Operational Current DC-13 (Ie) | (24 V) 2.8 A |
| (125 V) 0.55 A | |
| (250 V) 0.27 A | |
| Environmental | |
| Ambient Air Temperature | Operation -25 ... +70 °C |
| Storage -40 ... +70 °C | |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| RoHS Declaration | 1SBD251097E1000 |
| RoHS Information | Following EU Directive 2002/95/EC August 18, 2005 and amendment |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Certificates and Declarations | |
| CQC Certificate | CQC2004010305127663 |
| cUL Certificate | 9AKK107991A7379 |
| Declaration of Conformity - CCC | 2020980305001785 |
| Declaration of Conformity - CE | 1SBD250883U1000 |
| Declaration of Conformity - UKCA | 1SBD250886U1000 |
| Container Information | |
| Package Level 1 Units | bag 1 piece |
| Package Level 1 Width | 16 mm |
| Package Level 1 Depth / Length | 30 mm |
| Package Level 1 Height | 70 mm |
| Package Level 1 Gross Weight | 0.136 kg |
| Package Level 1 EAN | 3471522641250 |
| External Classifications and Standards | |
| ETIM 6 | EC000030 - End switch |
| ETIM 7 | EC000030 - End switch |
| ETIM 8 | EC000030 - End switch |
| eClass | V11.0 : 27272601 |
| UNSPSC | 39121500 |
