1SBN072808R1000 ABB LD40 Additional Terminal Block
1SBN072808R1000
072808
ABB
1 Pcs.
Automation > Accessories/spare parts for low-voltage switch technology
"A" FRCTLP
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
This Abb 1SBN072808R1000 ABB LD40 Additional Terminal Block acts as an auxiliary connection node used within electrical control panels to expand wiring capacity and distribute control signals. Terminal blocks organize complex wiring layouts while maintaining secure conductive paths.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85369010
- Data Sheet, Technical Information: 1SBC100214C0202
- Instructions and Manuals: FPTC407769P0001
- CAD Dimensional Drawing: 2CDC001079B0201
- Product Net Width: 43 mm
- Product Net Depth / Length: 48.3 mm
- Product Net Height: 40 mm
- Product Net Weight: 0.075 kg
- Rated Frequency (f): Main Circuit 50 / 60 Hz Rated Insulation Voltage (U i ): acc. to IEC 60947-5-1 690 V
- Degree of Protection: acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP10
- Tightening Torque: Cable Lug 2.5 N·m
- Terminal Type: Screw Terminals
- Suitable For: A30
- Product Name: Additional Terminal Block
More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85369010 |
| Popular Downloads | |
| Data Sheet, Technical Information | 1SBC100214C0202 |
| Instructions and Manuals | FPTC407769P0001 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Dimensions | |
| Product Net Width | 43 mm |
| Product Net Depth / Length | 48.3 mm |
| Product Net Height | 40 mm |
| Product Net Weight | 0.075 kg |
| Technical | |
| Rated Frequency (f) | Main Circuit 50 / 60 Hz |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 690 V |
| acc. to UL/CSA 600 V | |
| Degree of Protection | acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP10 |
| Tightening Torque | Cable Lug 2.5 N·m |
| Terminal Type | Screw Terminals |
| Suitable For | A30 |
| A40 | |
| AL30 | |
| AL40 | |
| Product Name | Additional Terminal Block |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2021-006202 |
| RoHS Declaration | 2CMT2021-006277 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006525 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 1SBD250835U1000 |
| Declaration of Conformity - UKCA | 1SBD250836U1000 |
| RINA Certificate | RINA_ELE172319XG001 |
| Container Information | |
| Package Level 1 Units | bag 1 piece |
| Package Level 1 Width | 80 mm |
| Package Level 1 Depth / Length | 80 mm |
| Package Level 1 Height | 45 mm |
| Package Level 1 Gross Weight | 0.075 kg |
| Package Level 1 EAN | 3471522199577 |
| External Classifications and Standards | |
| ETIM 7 | EC002498 - Accessories for low-voltage switch technology |
| ETIM 8 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| ETIM 9 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| UNSPSC | 39121410 |
| IDEA Granular Category Code (IGCC) | 4547 >> Terminal blocks |
