ABB 2CSF202007R1400 2CSF202007R1400 ABB FV202 AC-40/0,03 Resid. Current Dev. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

2CSF202007R1400 ABB FV202 AC-40/0,03 Resid. Current Dev.

2CSF202007R1400

202007

ABB

1 Pcs.

FV202 AC-40/0,03 - Resid. Current Dev. Int.dif.FV202AC-40/0.03 2p 40A AC 30mA

Automation > Residual current circuit breaker (RCCB)
SV200

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A residual current device like the Abb 2CSF202007R1400 monitors electrical current balance to instantly disconnect power when earth leakage is detected, mitigating shock risks. These units are typically installed upstream in distribution enclosures to provide fundamental earth fault safety for various load types. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Standards: IEC 61008
  • Operating Characteristic: Instantaneous
  • Type of Residual Current: AC type
  • Rated Residual Current: 30 mA
  • Rated Current (I n ): 40 A
  • Number of Poles: 2
  • Power Loss: at Rated Operating Conditions per Pole 2.4 W
  • Product Net Width: 0.035 m
  • Product Net Height: 0.085 m
  • Product Net Depth: 0.069 m
  • Product Net Weight: 0.200 kg
  • EAN: 8012542891703
  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85363030
  • Package Level 1 Units: 1 piece
  • Package Level 1 Width: 0.041 m

More info

▲

The RCCBs FV200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous AC and A types is particularly suitable for installation in domestic applications.

Ordering

  • EAN:
    8012542891703
  • Minimum Order Quantity:
    1 piece
  • Customs Tariff Number:
    85363030

Dimensions

  • Product Net Width:
    0.035m
  • Product Net Height:
    0.085m
  • Product Net Depth:
    0.069m
  • Product Net Weight:
    0.200kg

Container Information

  • Package Level 1 Units:
    1 piece
  • Package Level 1 Width:
    0.041 m
  • Package Level 1 Height:
    0.078 m
  • Package Level 1 Length:
    0.096 m
  • Package Level 1 Gross Weight:
    0.225 kg
  • Package Level 1 EAN:
    8012542891703

Technical

  • Standards:
    IEC 61008
  • Operating Characteristic:
    Instantaneous
  • Type of Residual Current:
    AC type
  • Rated Residual Current:
    30 mA
  • Rated Current (In):
    40 A
  • Number of Poles:
    2
  • Power Loss:
    at Rated Operating Conditions per Pole 2.4 W

Certificates and Declarations (Document Number)

Classifications

  • Object Classification Code:
    Q
  • ETIM 4:
    EC000003 - Residual current circuit breaker (RCCB)
  • ETIM 5:
    EC000003 - Residual current circuit breaker (RCCB)
