ABB 1SDA072567R1 1SDA072567R1 ABB E4.2H 4000 Ekip G Touch LSIG 3p WMP View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SDA072567R1 ABB E4.2H 4000 Ekip G Touch LSIG 3p WMP

1SDA072567R1

072567

ABB

1 Pcs.

E4.2H 4000 Ekip G Touch LSIG 3p WMP

Automation > Power circuit-breaker for trafo/generator/installation protection
E4.2

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
ABB EcoSolutions
ABB EcoSolutionsYes
ABB Site Meeting Group Waste To Landfill TargetUL 2799 Zero Waste To Landfill Validation available
End Of Life Disassembling Instructions9AKK108468A2363
Environmental Product Declaration - EPD9AKK108468A1904
9AKK108468A1910
Extended Product LifetimeLifetime Extension Services are Offered
Recyclability Rate of the Product acc. to EN45555Design for Closing Resource Loops - Standard EN45555 - 79.3 %
Material Compliance
REACH Declaration9AKK108466A1425
RoHS Declaration9AKK108466A1424
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
Toxic Substances Control Act - TSCA9AKK108467A8326
SCIPec3dc06a-d7b5-4dde-9741-49a0146ee458 Italy
Simplified SCIP0ec35afb-cf30-4f27-a6f5-5ee27c2503b9 Germany
cd59db36-c928-4156-b5ed-115d6077c16c Belgium
3c20bee5-ffbe-4793-b51f-297de45e8a7e Spain
832b851b-d342-4f62-b635-d9872a7a4ed6 Hungary
31beb416-ce5a-4fb1-afe8-4b668b93fc58 Norway
fac98eb7-3c10-46e6-b81f-867f653b7688 Netherlands
a3e27d0f-2090-45cb-8d9e-bd78476d4b66 Finland
7a9946fb-bfdf-48cf-91fe-99bc82451143 Greece
1cd0ff9c-139e-4765-84bd-6d6caf574a45 Estonia
38e72da8-6c83-4882-889b-d553b67173dc Germany
cc738dcb-09c3-472a-83b8-696e3cadc64b Germany
e73f13e8-ce85-4d8b-93a9-003641044ad0 Croatia
adf8376f-be03-498e-92de-0e126d44e124 Germany
ac42ca2d-9ea3-4c4e-a6b6-4d2124c69893 Denmark
a040f158-995d-471f-8154-fa434b5ce6a9 Germany
659a22f5-ba97-4c62-9363-41b5944f30bb Belgium
089e3398-90a4-4540-bb46-ab2e01e89077 Sweden
cb6941ad-0ecf-4dba-8fb7-790bfa6850a5 Poland
425caca8-5023-4d90-9168-3cbe092235e8 Hungary
e624507b-549d-4031-b522-678324778a27 France
e5cacef0-f854-4b62-a98f-ca4df3c7f755 France
0c03d394-981f-4e4c-b989-8d2dd0f9ea74 Sweden
cc102f01-f421-4625-adc7-f6298952fbe6 Bulgaria
20ea8375-a66b-4e1c-ad17-bd9b01a88116 Portugal
f697cbbb-a6bc-496b-ad6b-0d970a5aed0e Poland
a4a518d2-2187-40e7-9801-175e3d2b33a5 Czech Republic
0c631f22-5deb-423d-9bf0-b647eb791fe9 Poland
Environmental
Environmental Information9AKK108467A6707
Ordering
Order Code US and CanadaZ4HWERAN200A000000XX
EAN8015644764173
Minimum Order Quantity1 piece
Customs Tariff Number85362090
Dimensions
Product Net Width425 mm
Product Net Height425 mm
Product Net Depth / Length383 mm
Product Net Weight60 kg
Container Information
Package Level 1 Unitsbox 1 piece
Package Level 1 Width515 mm
Package Level 1 Height610 mm
Package Level 1 Depth / Length615 mm
Package Level 1 Gross Weight67 kg
Package Level 1 EAN8015644764173
Additional Information
Product Main TypeSACE Emax 2
Product NameAir Circuit Breaker
Product TypeAir Circuit Breaker
VersionW
Technical
Connecting Capacity4000 mm²
Current TypeAC
Electrical DurabilityUe =< 440 V 5000 cycle
Ue = 500 ... 690 V 4000 cycle
20 cycles per hour
Mechanical Durability15000 cycle
60 cycles per hour
Number of Poles3P
Power Loss900 W
Rated Current (In)4000 A
Rated Impulse Withstand Voltage (Uimp)acc. to IEC 60947-2 12 kV
Rated Insulation Voltage (Ui)AC 1000 V
Rated Operational Voltage690 V AC
Rated Service Short-Circuit Breaking Capacity (Ics)(220 V AC) 100 kA
(230 V AC) 100 kA
(380 V AC) 100 kA
(400 V AC) 100 kA
(415 V AC) 100 kA
(440 V AC) 100 kA
(500 V AC) 85 kA
(660 V AC) 85 kA
(690 V AC) 85 kA
Rated Service Short-Circuit Breaking Capacity, in % of Icu (Ics)100 %
Rated Short-time Withstand Current Low Voltage (Icw)for 1 s 85 kA
for 3 s 75 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu)(400 V AC) 100 kA
(415 V AC) 100 kA
(440 V AC) 100 kA
(500 V AC) 85 kA
(525 V AC) 85 kA
(690 V AC) 85 kA
Rated Uninterrupted Current (Iu)4000 A
Rated Voltage (Ur)690 V
Recommended Screw DriverM12
ReleaseEkip G Touch LSIG
Release TypeEL
Short-Circuit Performance LevelH
StandardsIEC
Sub-typeE4.2
Suitable for IT NetworksYes, 690V
Certificates and Declarations
Data Sheet, Technical Information1SDC200023D0209
Declaration of Conformity - CE9AKK106713A5545
EU Data Act Compliance Declaration1SDH002560A1001
Instructions and Manuals1SDH001000R0002
Instructions and Manuals (Part 2)1SDH001316R1002
External Classifications and Standards
ETIM 9EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10EC000228 - Power circuit-breaker for trafo/generator/installation protection
IDEA Granular Category Code (IGCC)4926 >> Air circuit breakers
Object Classification CodeQ
UNSPSC39121615
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
eClassV11.1 : 27370409

ETIM for 1SDA072567R1 Low-voltage industrial controls and switchgear (EC000228)
Feature Name Feature Value
Rated permanent current Iu (EF001389) 4000 A
Rated voltage (EF003977) 690 V
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz (EF007048) 100 kA
Overload release current setting (EF002336) 1600.0 A
Adjustment range short-term delayed short-circuit release (EF007129) 2400.0 A
Adjustment range undelayed short-circuit release (EF007131) 6000.0 A
Integrated earth fault protection (EF007296) Yes
Type of electrical connection of main circuit (EF006819) Connection at separate chassis part
Device construction (EF008240) Built-in device slide-in technique (withdrawable)
Suitable for DIN rail (top hat rail) mounting (EF007250) No
DIN rail (top hat rail) mounting optional (EF008904) No
Number of auxiliary contacts as normally closed contact (EF001377) 0
Number of auxiliary contacts as normally open contact (EF001376) 0
Number of auxiliary contacts as change-over contact (EF003531) 4
With switched-off indicator (EF007006) Yes
With integrated under voltage release (EF001390) No
Number of poles (EF001391) 3
Position of connection for main current circuit (EF006671) Connection at separate chassis part
Type of control element (EF006976) Push button
Complete device with protection unit (EF008906) Yes
Motor drive integrated (EF006697) No
Motor drive optional (EF007386) Yes
Degree of protection (IP) (EF005474) IP30
