ABB 1SDA058245R1 1SDA058245R1 ABB RATING PLUG EXTRACODIGO In3200A E3/6 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SDA058245R1 ABB RATING PLUG EXTRACODIGO In3200A E3/6

1SDA058245R1

058245

ABB

1 Pcs.

RATING PLUG EXTRACODIGO In3200A - E3/6 RATING PLUG In=3200A E3-6IEC E3-6UL EX.C

Automation > Accessories/spare parts for low-voltage switch technology
Service Breakers

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

1SDA058245R1 ABB RATING PLUG EXTRACODIGO In3200A E3/6 functions as a calibrated electronic module that defines the continuous current rating threshold for high-capacity air circuit breakers. Rating plugs of this specification allow operators to tailor breaker trip characteristics precisely to the load requirements of heavy industrial distribution grids.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • REACH Declaration: 9AKK108466A1425
  • RoHS Declaration: 9AKK108466A1424
  • RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
  • Conflict Minerals Reporting Template (CMRT): Document availability on demand
  • EAN: 8015644605322
  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85389099
  • Product Net Weight: 1 kg
  • Package Level 1 Units: 1 piece
  • Package Level 1 Gross Weight: 0.1 kg
  • Package Level 1 EAN: 8015644605322
  • Product Main Type: Accessories for Emax
  • Product Name: Accessory
  • Product Type: Accessory
  • Suitable For: E3, E4, E6
  • Suitable for Product Class: SACE Emax

More info

▲
Material Compliance
REACH Declaration9AKK108466A1425
RoHS Declaration9AKK108466A1424
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)Document availability on demand
Ordering
EAN8015644605322
Minimum Order Quantity1 piece
Customs Tariff Number85389099
Dimensions
Product Net Weight1 kg
Container Information
Package Level 1 Units1 piece
Package Level 1 Gross Weight0.1 kg
Package Level 1 EAN8015644605322
Additional Information
Product Main TypeAccessories for Emax
Product NameAccessory
Product TypeAccessory
Suitable ForE3, E4, E6
Suitable for Product ClassSACE Emax
Technical
Configuration TypeMounted only
Rated Current (In)3200 A
StandardsIEC
Certificates and Declarations
Data Sheet, Technical Information1SDC200006D0209
Declaration of Conformity - CE1SDL000165R0015
1SDL000165R0016
1SDL000165R0017
Instructions and Manuals1SDC200006D0209
External Classifications and Standards
Object Classification CodeQ
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)

Product Datasheet
