Images are for illustrative purposes only. Please refer to data sheet for details
2CSM277962R1801 ABB E 93/50 Fuse holder
2CSM277962R1801
277962
ABB
1 Pcs.
E 93/50 Fuse holder
Fuse holder base E93/50 50A 3p
E 93/50 Fuse disconnector
Automation > Holder for cylindrical fuse
E90 E930 E9F
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Abb E 93/50 Fuse holder (2CSM277962R1801) is a robust three-pole modular fuse base intended for industrial power distribution panels, facilitating safe circuit protection and disconnection under specified load conditions.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Suitable For: E 90
- Suitable for Product Class: Fuse holders
- Number of Protected Poles: 3
- Number of Poles: 3P
- Tightening Torque: 3...3.5 N·m
- Utilization Category: Connecting and disconnecting under no-load conditions - occasional actuation (AC-20B)
- Lock Type: Padlockable
- Sealing Type: Sealing Wire
- Material of Conductor: Copper
- Options Provided: No
- Recommended Screw Driver: Pozidriv 2
- Connecting Capacity: Rigid 2.5…25 mm²
- Fuse Size: 14x51 mm
- Operating Humidity (RH amb ): max. 90% with temp. +20 °C 50% with max. temp. +40 °C
- Rated Operational Current AC (I e ): 50 A
- Rated Voltage (U r ): acc. To IEC 690 V
More info
▲| Technical | |
|---|---|
| Suitable For | E 90 |
| Suitable for Product Class | Fuse holders |
| Number of Protected Poles | 3 |
| Number of Poles | 3P |
| Tightening Torque | 3...3.5 N·m |
| Utilization Category | Connecting and disconnecting under no-load conditions - occasional actuation (AC-20B) |
| Lock Type | Padlockable |
| Sealing Type | Sealing Wire |
| Material of Conductor | Copper |
| Options Provided | No |
| Recommended Screw Driver | Pozidriv 2 |
| Connecting Capacity | Rigid 2.5…25 mm² |
| Rigid Stranded 2.5…35 mm² | |
| Fuse Size | 14x51 mm |
| Operating Humidity (RHamb) | max. 90% with temp. +20 °C 50% with max. temp. +40 °C |
| Rated Operational Current AC (Ie) | 50 A |
| Electrical | |
| Rated Voltage (Ur) | acc. To IEC 690 V |
| acc. To UL 690 V | |
| Rated Operational Voltage | AC-20B 690 V |
| Rated Insulation Voltage (Ui) | 1 kV |
| Rated Frequency (f) | 50/60 Hz |
| Power Loss | at Rated Operating Conditions per Pole 5 W |
| Material Compliance | |
| RoHS Declaration | 2CSC444009D2701 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date | 01/01/2014 0.00.00 |
| REACH Declaration | 9AKK108467A9482 |
| REACH Information | True - contains substances > 0.1 mass percentage |
| REACH Date | 20240429 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer |
| Environmental | |
| Ambient Air Temperature | Storage -5...+40 °C |
| Storage Operation -25...+70 °C | |
| Degree of Protection | IP20 |
| Resistance to Vibrations | 1 mm 2 … 13 Hz |
| Resistance to Shock acc. to IEC 60068-2-27 | 15g 18 shocks 11 ms |
| Environmental Information | See RoHS Information |
| Dimensions | |
| Width in Number of Modular Spacings | 4.5 |
| Product Net Width | 80.1 mm |
| Product Net Height | 96.5 mm |
| Product Net Depth / Length | 73.26 mm |
| Product Net Weight | 285 g |
| Built-In Depth (t2) | 73.26 mm |
| Ordering | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Gross Weight | 0.330 kg |
| E-Number (Finland) | 3017010 |
| E-Number (Norway) | 1416153 |
| Certificates and Declarations | |
| BV Certificate | 9AKK108467A0329 |
| CCC Certificate | 9AKK108467A0342 |
| Declaration of Conformity - CE | 2CSC444009D2701 |
| KRS Certificate | 9AKK108467A0338 |
| LR Certificate | 9AKK108467A0332 |
| RINA Certificate | 9AKK107992A0866 |
| UL Certificate | 9AKK107992A1040 |
| Installation | |
| Mounting Type | DIN-Rail |
| Popular Downloads | |
| Data Sheet, Technical Information | 2CSC444002B0204 |
| External Classifications and Standards | |
| ETIM 9 | EC002705 - Holder for cylindrical fuse |
| ETIM 10 | EC002705 - Holder for cylindrical fuse |
| UNSPSC | 39121624 |
| eClass | V11.0 : 27142121 |
| IDEA Granular Category Code (IGCC) | 4974 >> Holder for cylindrical fuse |
| Object Classification Code | F |
| Certification Agency | BV |
| Korean register | |
| CCC | |
| EAC | |
| Standardization Body | UL |
